- Programmable
- Dimming Functionalities:
- 0-10V, PWM, Multiple Timers
- Controls-Ready:
- Dim-to-Off with Low Standby Power
- Always-On Auxiliary Power 12V/200mA
- Input Surge Protection:
- 6kV DM, 10kV CM
- Thermal Sensing and Protection for LED Module
- Output Lumen Compensation
- TYPE HL, for use in Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
99,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.70 x 2.66 x 1.56
Millimeters (L x W x H)
221 x 67.5 x 39.7
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 700 – 1050 mA | 700 mA |
249 ~ 528 Vac |
75 – 214 Vdc |
150 W |
ESD-150S105DT |
| 1400 – 2100 mA | 1400 mA | 38 – 107 Vdc | ESD-150S210DT | ||
| 2450 – 3500 mA | 2500 mA | 22 – 61 Vdc | ESD-150S350DT | ||
| 3850 – 5600 mA | 4200 mA | 14 – 39 Vdc | ESD-150S560DT |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guidelines (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
