- Compact Metal Housing
- Input Surge Protection:
- 4kV DM, 6kV CM
- Built-in Protection for Unstable Input Lines:
- Input Under Voltage Protection
- Input Over Voltage Protection
- Low Total Harmonic Distortion (THD)
- Suitable for Built-in Use and Class I Luminaires
- SELV Output
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
84,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
3.15 x 2.52 x 1.26
Millimeters (L x W x H)
80 x 64 x 32
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 350 mA |
90 ~ 305 Vac |
37 – 74 Vdc |
26 W |
EUC-026S050STM0003 |
| 500 mA | 26 – 52 Vdc | EUC-026S070STM0004 | ||
| 600 mA | 22 – 43 Vdc | EUC-026S070STM0002 | ||
| 700 mA | 20 – 37 Vdc | EUC-026S070STM | ||
| Note: Models listed are not all-inclusive. For additional models please contact our sales department. | ||||
|
