Cost-Optimized, Compact Controls-Ready LED Drivers - Inventronics

Inventronics EUM and ESM MT and MG series offer OEMs extreme design flexibility with a cost-optimized and compact Controls-Ready option to better power daylight and occupancy sensors. There are several power levels offered that all provide full-power at a wide output current range. The EUM family operates at 90-305Vac while the ESM series operates at 249-528Vac.

This IP66 & IP67 LED driver family is equipped with 0-10V isolated dimming, Dim-to-Off, Always-On auxiliary power of 12VDC, 250mA allowing for reduced costs on specialized controls and a simplified installation. OEMs are also provided the added convenience of UL Class P models (MT Series) and models with a Global cable to help reduce inventory SKUs (MG Series).

For even more convenience, the EUM and ESM Mx family provides users the ability to utilize crucial driver data with Inventronics proprietary digital dimming communications protocol. To learn more about the benefits of Digital Dimming, please read our white paper: Digital Dimming: Inventronics Proprietary Driver Health Solution

ESM-240SxxxMG

The ESM-240SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that offer programmability, isolated dimming, low inrush current, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528 Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 240 W

Current Range: .7 - 6.7 A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-240SxxxMT

The ESM-240SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer programmability, isolated dimming, low inrush current and a high level of input surge protection. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 240 W

Current Range: 0.7 - 6.7 A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-320SxxxMG

The ESM-320SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that offer programmability, isolated dimming, low inrush current, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528 Vac and provide the full 320W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 320 W

Current Range: .7 - 7.6 A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-320SxxxMT

The ESM-320SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer programmability, isolated dimming, low inrush current and a high level of input surge protection. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528Vac and provide the full 320W at a wide output current range. They are ideal for horticulture, high bay, high mast, horticulture and stadium lighting.

Power Level: 320 W

Current Range: 0.7 - 7.6 A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-680SxxxMG

The ESM-680SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that offer programmability, isolated dimming, low inrush current, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528 Vac and provide the full 680W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 680 W

Current Range: 1.25-15A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-680SxxxMT

The ESM-680SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer programmability, isolated dimming, low inrush current and a high level of input surge protection. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528Vac and provide the full 680W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 680 W

Current Range: 1.25 -15.0A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-075SxxxMG

The EUM-075SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 75W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 75 W

Current Range: 0.7-2.1A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-075SxxxMT

The EUM-075SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 75W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 75 W

Current Range: 0.7-2.1A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-100SxxxMG

The EUM-100SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 100W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 100 W

Current Range: 0.7-2.8A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-100SxxxMT

The EUM-100SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 100W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 100 W

Current Range: 0.7-2.8A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-150SxxxMG

The EUM-150SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 150W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 150 W

Current Range: 0.7-4.2A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-150SxxxMT

The EUM-150SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 150W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 150 W

Current Range: 0.7-4.2A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-200SxxxMG

The EUM-200SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 200 W

Current Range: 0.53-5.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-200SxxxMT

The EUM-200SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers providing Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 200 W

Current Range: 0.53-5.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-240SxxxMG

The EUM-240SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 240 W

Current Range: 0.7-6.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-240SxxxMT

The EUM-240SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers providing Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 240 W

Current Range: 0.7-6.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-320SxxxMG

The EUM-320SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 320W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 320 W

Current Range: .7-7.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-320SxxxMT

The EUM-320SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 320W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 320 W

Current Range: 0.7-7.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-680SxxxMG

The EUM-680SxxxMG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 680W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 680 W

Current Range: 1.25-15.0A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-680SxxxMGS

The EUM-680SxxxMGS series is suitable for global use. They are equipped with panel mount connectors and brackets for easy installation and design flexibility. They consist of IP66/IP67 LED drivers that provide Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They operate from 90-305Vac and provide the full 680W at a wide output current range. They are ideal for horticulture, high mast, stadium and aquaculture lighting applications.

Power Level: 680 W

Current Range: 1.25-15.0A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-680SxxxMT

The EUM-680SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 680W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 680 W

Current Range: 1.25-1.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
