Driver Health Monitoring LED DriversInventronics provides a digital dimming communication protocol that allows users to read back information from compatible drivers over a UART bus.  This feature allows critical information to be analyzed by a control system to monitor driver health and help extend driver life. To learn more about these drivers and their innovative design, you can read the app note here.



The ESD-480SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 249-528Vac and provide 480W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 480W
Current Range: 1.05-10.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The ESD-480SxxxDV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 249-528Vac and provide 480W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 480W
Current Range: 1.05-10.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The EUD-075SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-075SxxxDV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The 2nd Generation EUD-096SxxxDTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The 2nd Generation EUD-096SxxxDVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 96W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The 2nd Generation EUD-150SxxxDTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for highbay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: DM 6 kV, CM 10 kV
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The 2nd Generation EUD-150SxxxDVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The 2nd Generation EUD-200SxxxDTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The 2nd Generation EUD-200SxxxDVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The 2nd Generation EUD-240SxxxDTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The 2nd Generation EUD-240SxxxDVA is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUM-200SxxxLG series is suitable for global use. They consist of global, IP66/IP67 LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, a high level of surge protection and a global cable that helps reduce SKUs for world-wide use. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for high bay, high mast and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
The EUM-200SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for high bay, high mast and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
