Next Generation Platform, Class P LED Drivers - Inventronics

Inventronics EUM-xT and ESM-xT Family leverages the new, next generation platform offering an optimized design with more design flexibility and a simplified way to conduct hi-pot testing without sacrificing quality, performance or surge protection. The EUM-xT and ESM-xT family are UL Class P Listed providing the freedom of substitution without new testing and bring your products to market faster. Their programmable interface and constant-power operation allow for in-house customization which achieves optimal results and various current configurations without the need of powering on the driver. They supply improved safety with a wide range of isolated dimming options including 1-5V, 1-10V, PWM and multiple timers. They offer a high level of design flexibility with DALI-2 D4i (EUM-BT), NFC programming (EUM-LT, ESM-LT, EUM-BT and ESM-BT), Controls-Ready Features (EUM-LT, ESM-LT, EUM-MT, ESM-MT, EUM-BT and ESM-BT), driver health monitoring (EUM-LT, ESM-LT, EUM-MT, ESM-MT, EUM-BT and ESM-BT) and power monitoring (EUM-LT, ESM-LT, EUM-BT and ESM-BT) . The EUM-xT provide 90-305Vac and the ESM-xT provide 249-528Vac.

ESM-150SxxxBT

The ESM-150SxxxBT series is suitable for North American use. They consist of IP66/IP67 LED drivers that offer NFC wireless programming, driver health monitoring with DALI-2 D4i, design flexibility and a high level of surge protection. They provide integrated AC power monitoring, Always-On Auxiliary and Dim-to-Off functionality for powering low voltage controls. They operate from 249-528Vac and provide the full 150W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 150W

Current Range: .70-4.20A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: DALI-2, D4i, Multiple TImers

ESM-150SxxxDT

The ESM-150SxxxDT series is suitable for North American use. They consist of programmable IP66/IP67 UL Class P drivers that offer isolated dimming, design flexibility, a high level of surge protection and more compact housing. They operate from 249-528Vac and provide 150W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.

Power Level: 150W

Current Range: .70-4.20A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 10V, 10V PWM, Multiple Timers

ESM-240SxxxDT

The ESM-240SxxxDT series is suitable for North American use. They consist of programmable IP66/IP67 UL Class P drivers that offer isolated dimming, design flexibility, a high level of surge protection and more compact housing. They operate from 249-528Vac and provide 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.

Power Level: 240W

Current Range: .70-4.90A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 10V, 10V PWM, Multiple Timers

ESM-240SxxxLT

The ESM-240SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 249-528Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 240 W

Current Range: 0.7-6.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-240SxxxMT

The ESM-240SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer programmability, isolated dimming, low inrush current and a high level of input surge protection. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 240 W

Current Range: 0.7 - 6.7 A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-320SxxxDT

The ESM-320SxxxDT series is suitable for North American use. They consist of programmable IP66/IP67 UL Class P drivers that offer isolated dimming, design flexibility, a high level of surge protection and more compact housing. They operate from 249-528Vac and provide 320W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.

Power Level: 320W

Current Range: .70-6.70A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 10V, 10V PWM, Multiple Timers

ESM-320SxxxLT

The ESM-320SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 249-528Vac and provide the full 320W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 320 W

Current Range: 0.7-7.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-320SxxxMT

The ESM-320SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer programmability, isolated dimming, low inrush current and a high level of input surge protection. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528Vac and provide the full 320W at a wide output current range. They are ideal for horticulture, high bay, high mast, horticulture and stadium lighting.

Power Level: 320 W

Current Range: 0.7 - 7.6 A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

ESM-680SxxxMT

The ESM-680SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer programmability, isolated dimming, low inrush current and a high level of input surge protection. They provide Dim-to-Off functionality and Auxiliary Power for powering low voltage controls. They operate from 249-528Vac and provide the full 680W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 680 W

Current Range: 1.25 -15.0A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-030SxxxDT

The EUM-030SxxxDT series is suitable for North American use. They consist of IP66/IP67 Class P, programmable LED drivers that offer isolated dimming, design flexibility and built-in surge protection. They operate from 90-305Vac and provide the full 30W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.

Power Level: 30 W

Current Range: 0.30-1.05A

Surge: 4 kV DM, 6 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers

EUM-050SxxxDF

The EUM-050SxxxDF series is suitable for North American use. They consist of IP66 Class P, programmable LED drivers that offer isolated dimming, design flexibility and built-in surge protection. They operate from 90-305Vac and provide the full 50W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.

Power Level: 50 W

Current Range: 0.55-1.5A

Surge: 4 kV DM, 6 kV CM

IP Rating: IP66

Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers

EUM-050SxxxDT

The EUM-050SxxxDT series is suitable for North American use. They consist of IP66/IP67 Class P, programmable LED drivers that offer isolated dimming, design flexibility and built-in surge protection. They operate from 90-305Vac and provide the full 50W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.

Power Level: 50 W

Current Range: 0.55-1.5A

Surge: 4 kV DM, 6 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers

EUM-075SxxxBT

The EUM-075SxxxBT series is suitable for North American use. They consist of IP66/IP67 LED drivers that offer NFC wireless programming, driver health monitoring with DALI-2 D4i, design flexibility and a high level of surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 75W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 75 W

Current Range: 0.7-2.1A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: DALI-2 D4i, Multiple Timers

EUM-075SxxxDT

The EUM-075SxxxDT series is suitable for North American use. They consist of IP66/IP67 UL Class P LED drivers that offer isolated dimming, design flexibility, more compact housing and a high level of surge protection. They operate from 90-305Vac and provide the full 75W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 75 W

Current Range: 0.7-2.1A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers

EUM-075SxxxLT

The EUM-075SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 75W at a wide output current range. They are ideal for bay, area and roadway lighting applications.

Power Level: 75 W

Current Range: 0.7-2.1A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-075SxxxMT

The EUM-075SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 75W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 75 W

Current Range: 0.7-2.1A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-100SxxxBT

The EUM-100SxxxBT series is suitable for North American use. They consist of IP66/IP67 LED drivers that offer NFC wireless programming, driver health monitoring with DALI-2 D4i, design flexibility and a high level of surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 100W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 100 W

Current Range: 0.7-2.8A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: DALI-2 D4i, Multiple Timers

EUM-100SxxxDT

The EUM-100SxxxDT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer isolated dimming, design flexibility, more compact housing and a high level of surge protection. They operate from 90-305Vac and provide the full 100W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 100 W

Current Range: 0.35-2.8A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers

EUM-100SxxxLT

The EUM-100SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 100W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 100 W

Current Range: 0.7-2.8A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-100SxxxMT

The EUM-100SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 100W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 100 W

Current Range: 0.7-2.8A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-150SxxxBT

The EUM-150SxxxBT series is suitable for North American use. They consist of IP66/IP67 LED drivers that offer NFC wireless programming, driver health monitoring with DALI-2 D4i, design flexibility and a high level of surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 150W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 150 W

Current Range: 0.7-4.2A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: DALI-2 D4i, Multiple Timers

EUM-150SxxxDT

The EUM-150SxxxDT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer isolated dimming, design flexibility, more compact housing and a high level of surge protection. They operate from 90-305Vac and provide the full 150W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 150 W

Current Range: 0.7-4.2A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers

EUM-150SxxxLT

The EUM-150SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 150W at a wide output current range. They are ideal for high bay, high mast, area and roadway lighting applications.

Power Level: 150 W

Current Range: 0.7-4.2A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-150SxxxMT

The EUM-150SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 150W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 150 W

Current Range: 0.7-4.2A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-200SxxxBT

The EUM-200SxxxBT series is suitable for North American use. They consist of IP66/IP67 LED drivers that offer NFC wireless programming, driver health monitoring with DALI-2 D4i, design flexibility and a high level of surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 200 W

Current Range: 0.7-5.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: DALI-2 D4i, Multiple Timers

EUM-200SxxxDT

The EUM-200SxxxDT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 200 W

Current Range: 0.7-5.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers

EUM-200SxxxLT

The EUM-200SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 200 W

Current Range: 0.7-5.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-200SxxxMT

The EUM-200SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers providing Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 200 W

Current Range: 0.53-5.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-240SxxxBT

The EUM-240SxxxBT series is suitable for North American use. They consist of IP66/IP67 LED drivers that offer NFC wireless programming, driver health monitoring with DALI-2 D4i, design flexibility and a high level of surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 240 W

Current Range: 0.7-6.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: DALI-2 D4i, Multiple Timers

EUM-240SxxxDT

The EUM-240SxxxDT series is suitable for North American use. They consist of IP66/IP67 Class P, programmable LED drivers that offer isolated dimming, design flexibility, more compact housing and a high level of surge protection. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 240 W

Current Range: 0.7-6.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers

EUM-240SxxxLT

The EUM-240SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrate AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 240 W

Current Range: 0.7-6.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-240SxxxMT

The EUM-240SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers providing Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast and roadway lighting applications.

Power Level: 240 W

Current Range: 0.7-6.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-320SxxxLT

The EUM-320SxxxLT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers that offer NFC wireless programming, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They provide integrated AC power monitoring and Dim-to-Off functionality for powering low voltage controls. They operate from 90-305Vac and provide the full 320W at a wide output current range. They are ideal for high bay, high mast, horticulture and stadium lighting.

Power Level: 320 W

Current Range: 0.7-7.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-320SxxxMT

The EUM-320SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 320W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 320 W

Current Range: 0.7-7.6A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming

EUM-680SxxxMT

The EUM-680SxxxMT series is suitable for North American use. They consist of IP66/IP67 Class P LED drivers with Always-On Auxiliary Power and Dim-to-Off functionality for powering low voltage controls. They also offer programmability, driver health monitoring with digital dimming, isolated dimming, design flexibility, more compact design and a high level of input surge protection. They operate from 90-305Vac and provide the full 680W at a wide output current range. They are ideal for high bay, area and roadway lighting applications.

Power Level: 680 W

Current Range: 1.25-1.7A

Surge: 6 kV DM, 10 kV CM

IP Rating: IP66/IP67

Dimming: Isolated 0 - 10V, PWM, Multiple Timers, Digital Dimming
