• Constant-Power at a Wide Output Current Range
  • Wireless Programming via Near Field Communication (NFC)
  • Dimming Controls:
    • 1-10V, Multiple Timers
  • High Level Input Surge Protection:
    • 6kV DM, 10kV CM
  • Output Lumen Compensation
  • End-of-Life Indicator
  • IP20 Design and Suitable for Outdoor Applications in Luminaires with IP>54
  • Suitable for Luminaires with Protection Class I and II
  • Complies with Zhaga Interface Specification Book 13
  • 8 Year Warranty

Life Time

120,000 hours @ Case Temperature 75°C

Dimensions

Inches (L x W x H)
5.24 x 3.03 x 1.42

Millimeters (L x W x H)
133 x 77 x 36

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
450 – 700 mA 530 mA 176 ~ 305 Vac
171 – 275 Vdc
57 – 178 Vdc 80 W EBS-080S070DT2
700 – 1050 mA 700 mA 38 – 114 Vdc EBS-080S105DT2
1050 – 1500 mA 1050 mA 27 – 76 Vdc EBS-080S150DT2
