This Product has been Discontinued.
- Dimming Controls:
- DS: 0-10V
- PS: Non-Dimming
- Class 2 and SELV Output
- Improved Performance
- UL Type TL
- 5 Year Warranty
Life Time
91,100 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
3.07 x 3.15 x 1.06
Millimeters (L x W x H)
78 x 80 x 27
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 350 mA |
90 ~ 305 Vac |
38 – 75 Vdc |
26 W |
EUC-026S035DS(PS) |
| 450 mA | 28 – 56 Vdc | EUC-026S045DS(PS) | ||
| 530 mA | 25 – 49 Vdc | EUC-026S053DS(PS) | ||
| 700 mA | 19 – 37 Vdc | EUC-026S070DS(PS) | ||
| 1050 mA | 13 – 25 Vdc | EUC-026S105DS(PS) | ||
| 1400 mA | 10 – 19 Vdc | EUC-026S140DS(PS) | ||
| 1750 mA | 8 – 15 Vdc | EUC-026S175DS(PS) |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guidelines (Updated September 2018)
|
