• Wireless Programming via Near Field Communication (NFC)
    • Compatible with Zhaga Book 24 Programmers
  • Constant Power at Wide Output Current Range
  • Flicker-Free
  • Dimming Controls:
    • Isolated 1-10V (DT Models)
    • Minimum Dimming Levels with 5% or 10% Settable (DT Models)
    • Non-Dimming (ST Models)
  • Input Surge Protection:
    • 6kV DM, 6kV CM
  • IP54 and UL Dry & Damp Location
  • Class 2 & SELV Output
  • UL Class P
  • Suitable for Class I Luminaires
  • 5 Year Warranty

Life Time

107,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.37 x 1.71 x 1.26

Millimeters (L x W x H)
212.6 x 43.5 x 32

Certifications

Full-Power Current RangeDefault Output CurrentInput Voltage RangeOutput Voltage RangeMax. Output PowerModel Number
700 – 1050 mA700 mA90 – 305 Vac

127 – 250 Vdc

53 – 137 Vdc95 WLUN-095S105DT(ST)
1050 – 1500 mA1050 mA37 – 91 VdcLUN-095S150DT(ST)
1750 – 2800 mA2300 mA20 – 54 VdcLUN-095S280DT(ST)
File Name
LED Driver Installation Instructions (Updated March 2015)
LED Driver Installation Guideline (Updated September 2018)
Programming Interface Device Driver- Install First (Updated March 2015)
Design-In Guide for Programmable Drivers (Updated September 2018)
