Programmable LED Drivers

Inventronics offers one of the most extensive lines of programmable LED drivers in the industry. Their constant-power programmable capability delivers full power over a wide-range of output currents giving you just what you need for any application.   With drivers currently ranging from 25W to 1200W, they help reduce the number of driver SKUs needed without adding costs or compromising performance.  They are convenient and flexible with multiple dimming options and Controls-Ready models. Their superior thermal performance ensures they are rugged, reliable and provide longer lifetimes at higher case temperatures.

The EBD-075SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers designed to provide enahnced features for a more flexible performance. They operate from 176-305Vac and provide the full 75W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.
Power Level: 75 W
Current Range: 0.7-2.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EBD-100SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers designed to provide enhanced features for a more flexible performance. They operate from 176-305Vac and provide the full 100W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.
Power Level: 100 W
Current Range: 0.7-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
This series has been discontinued. Instead, please see the EUK-150SxxxDV series. The EBD-150SxxxDVA series is suitable for global use (except North America). They consist of programmable IP67 LED drivers designed to provide enhanced features for a more flexible performance. They operate from 176-305Vac and provide the full 150W at a wide output current range. They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.7-4.2A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EBD-200SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers designed to provide enhanced features for a more flexible performance. They operate from 176-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EBD-240SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers designed to provide enhanced features for a more flexible performance. They operate from 176-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EBD-255SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers designed to provide enhanced features for a more flexible performance. They operate from 176-305Vac and provide the full 255W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 255 W
Current Range: 0.7-1.05A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EBS-040SxxxBTE series is suitable for global use (except North America). They consist of 40W, DALI certified, programmable IP20 LED drivers that operate from 176-305Vac. They are Controls-Ready and designed in a Zhaga compatible form factor with convenient push terminals that provide flexibility and easier installation. They are ideal for indoor and outdoor use such as street, area and industrial lighting applications.
Power Level: 40 W
Current Range: .45-1.05A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP20
Dimming: DALI, AC Dim, Multiple Timers
The EBS-040SxxxDTE series is suitable for global use (except North America). They consist of 40W Controls-Ready, programmable IP20 LED drivers that operate from 176-305Vac. They are designed in a Zhaga compatible form factor with convenient push terminals that provide flexibility and easier installation. They are ideal for indoor and outdoor use such as street, area and industrial lighting applications.
Power Level: 40 W
Current Range: .45-1.05A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP20
Dimming: 0 - 10V, PWM, Multiple Timers
The EBS-080SxxxBTE series is suitable for global use (except North America). They consist of 80W, DALI certified, programmable IP20 LED drivers that operate from 176-305Vac. They are Controls-Ready and designed in a Zhaga compatible form factor with convenient push terminals that provide flexibility and easier installation. They are ideal for indoor and outdoor use such as street, area and industrial lighting applications.
Power Level: 80 W
Current Range: .45-1.05A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP20
Dimming: DALI, AC Dim, Multiple Timers
The EBS-080SxxxDTE series is suitable for global use (except North America). They consist of 80W Controls-Ready, programmable IP20 LED drivers that operate from 176-305Vac. They are designed in a Zhaga compatible form factor with convenient push terminals that provide flexibility and easier installation. They are ideal for indoor and outdoor use such as street, area and industrial lighting applications.
Power Level: 80 W
Current Range: .45-1.05A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP20
Dimming: 0 - 10V, PWM, Multiple Timers
The EBS-120SxxxBTE series is suitable for global use (except North America). They consist of 120W, DALI certified, programmable IP20 LED drivers that operate from 176-305Vac. They are Controls-Ready and designed in a Zhaga compatible form factor with convenient push terminals that provide flexibility and easier installation. They are ideal for indoor and outdoor use such as street, area and industrial lighting applications.
Power Level: 120 W
Current Range: 0.5-1.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP20
Dimming: DALI, AC Dim, Multiple Timers
The EBS-120SxxxDTE series is suitable for global use (except North America). They consist of 120W Controls-Ready, programmable IP20 LED drivers that operate from 176-305Vac. They are designed in a Zhaga compatible form factor with convenient push terminals that provide flexibility and easier installation. They are ideal for indoor and outdoor use such as street, area and industrial lighting applications.
Power Level: 120 W
Current Range: 0.5-1.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP20
Dimming: 0 - 10V, PWM, Multiple Timers
The EBS-160SxxxBTE series is suitable for global use (except North America). They consist of 160W, DALI certified, programmable IP20 LED drivers that operate from 176-305Vac. They are Controls-Ready and designed in a Zhaga compatible form factor with convenient push terminals that provide flexibility and easier installation. They are ideal for indoor and outdoor use such as street, area and industrial lighting applications.
Power Level: 160 W
Current Range: .45-1.05A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP20
Dimming: DALI, AC Dim, Multiple Timers
The EBS-160SxxxDTE series is suitable for global use (except North America). They consist of 160W Controls-Ready, programmable IP20 LED drivers that operate from 176-305Vac. They are designed in a Zhaga compatible form factor with convenient push terminals that provide flexibility and easier installation. They are ideal for indoor and outdoor use such as street, area and industrial lighting applications.
Power Level: 160 W
Current Range: .45-1.05A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP20
Dimming: 0 - 10V, PWM, Multiple Timers
The Ultra-high-powered EFD-1K2SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance while eliminating the need for a multiple driver design. They operate from 180-528Vac and provide the full 1200W at a wide output current range. They are designed to provide high power solutions and are ideal for high mast, airport, aquaculture, horticulture, port and sports lighting applications.
Power Level: 1200 W
Current Range: 3.36-7.4A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers
The Ultra-high-powered EFD-1K2SxxxDV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance while eliminating the need for a multiple driver design. They operate from 180-528Vac and provide the full 1200W at a wide output current range. They are designed to provide high power solutions and are ideal for high mast, airport, aquaculture, horticulture, port and sports lighting applications.
Power Level: 1200 W
Current Range: 3.36 - 7.4 A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers
The ESD-096SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 249-528Vac and provide 96W at a wide output current range. They are ideal for low bay, area and street lighting applications.
Power Level: 96
Current Range: 0.45-3.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The ESD-150SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 249-528Vac and provide 150W at a wide output current range. They are ideal for high bay, tunnel, and roadway lighting applications.
Power Level: 150
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The ESD-240SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 249-528Vac and provide 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240W
Current Range: 0.7-6.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The ESD-320SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 249-528Vac and provide 320W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 320 A
Current Range: 1.05-6.2A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The ESD-600SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 249-528Vac and provide 600W at a wide output current range. They are ideal for high mast, entertainment, horticulture, aquaculture and other high-power lighting applications. The ESD-600 series is a great option to replace multiple lower wattage drivers.
Power Level: 600 W
Current Range: 1.36 - 12.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The ESD-600SxxxDV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 249-528Vac and provide 600W at a wide output current range. They are ideal for high mast, entertainment, horticulture, aquaculture and other high-power lighting applications. The ESD-600 series is a great option to replace multiple lower wattage drivers.
Power Level: 600 W
Current Range: 1.36-12.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The DALI-certified EUD-075SxxxBT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The DALI-certified EUD-075SxxxBV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The EUD-075SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-075SxxxDV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 96W at a wide output current range.  They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 96 W
Current Range: 0.45-3.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation, DALI-certified EUD-096SxxxBTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 96W at a wide output current range.  They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 96 W
Current Range: 0.45-3.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation, DALI-certified EUD-096SxxxBVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 96W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 96W at a wide output current range.  They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 96 W
Current Range: 0.45-3.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation EUD-096SxxxDTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 75W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-096SxxxDTL series is suitable for North American use. They are really in a league of their own. These Controls-Ready, programmable IP67 LED drivers are designed without electrolytic capacitors to ensure an ultra-long lifetime. They provide the full 96W at a wide range of output currents and operate at 90-305Vac. They also include all the enhanced features to provide an industry-leading performance. They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 96W at a wide output current range.  They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 96 W
Current Range: 0.45-3.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation EUD-096SxxxDVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 96W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-096SxxxDVL series is suitable for global use (except North America). They are really in a league of their own. These Controls-Ready, programmable IP67 LED drivers are designed without electrolytic capacitors to ensure an ultra-long lifetime. They provide the full 96W at a wide range of output currents and operate at 90-305Vac. They also include all the enhanced features to provide an industry-leading performance. They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-100SxxxDD series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance.They provide Class II, double insulation and operate from 90-305Vac while delivering the full 100W at a wide output current range.  They are ideal for low bay, tunnel and street lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 100 W
Current Range: 0.7-2.1A
Surge: 10 kV DM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
This series is not recommended for new design. Instead, please see the improved features of the EUD-150SxxxBTA series. The series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.65-5.2A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation, DALI-certified EUD-150SxxxBTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI
This series has been discontinued. Instead, please see the improved features of the EUD-150SxxxBVA series. The series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.65-5.2A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation, DALI-certified EUD-0150SxxxBVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation EUD-150SxxxDDA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They provide Class II, double insulation and operate from 90-305Vac while delivering the full 150W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-2.1A
Surge: 10 kV DM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.65-5.2A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation EUD-150SxxxDTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for highbay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: DM 6 kV, CM 10 kV
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-150SxxxDTL series is suitable for North American use. They really are in a league of their own. These Controls-Ready, programmable IP67 LED drivers are designed without electrolytic capacitors to ensure an ultra-long lifetime. They provide the full 150W at a wide range of output currents and operate at 90-305Vac. They also include all the enhanced features to provide an industry-leading performance. They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.45-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.65-5.2A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation EUD-150SxxxDVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 150W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-150SxxxDVL series is suitable for global use (except North America). They are really in a league of their own. These Controls-Ready, programmable IP67 LED drivers are designed without electrolytic capacitors to ensure an ultra-long lifetime. They provide the full 150W at a wide range of output currents and operate at 90-305Vac. They also include all the enhanced features to provide an industry-leading performance. They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.45-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
This series is not recommended for new design.The DALI-certified EUD-200SxxxBD series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They provide Class II, double insulation and operate from 90-305Vac while delivering the full 200W at a wide output current range.  They are ideal for high bay, high mast, arena and roadway lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 200 W
Current Range: 0.7-1.5A
Surge: 6 kV DM
IP Rating: IP67
Dimming: DALI
This series has been discontinued. Instead, please see the improved features of the EUD-200SxxxBTA series. The series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-4.9A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation, DALI-certified EUD-200SxxxBTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
This series has been discontinued. Instead, please see the improved features of the EUD-200SxxxBVA series. The series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-4.9A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation, DALI-certified EUD-200SxxxBVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6 A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The EUD-200SxxxDD series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They provide Class II, double insulation and operate from 90-305Vac while delivering the full 200W at a wide output current range.  They are ideal for high bay, high mast, arena and roadway lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 200 W
Current Range: 0.7-1.5A
Surge: 6 kV DM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-4.9A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation EUD-200SxxxDTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for high bay, high mast, arena and roadway lighting applications..
Power Level: 200 W
Current Range: 0.7-4.9A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation EUD-200SxxxDVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
This series has been discontinued. Instead, please see the improved features of the EUD-200SxxxDTA paired with our CNV-DMXR. The series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for arena, theatrical and architectural lighting applications.
Power Level: 200 W
Current Range: 0.7-4.9A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DMX512
This series has been discontinued. Instead, please see the improved features of the EUD-200SxxxDVA paired with our CNV-DMXR. The series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 200W at a wide output current range.  They are ideal for arena, theatrical and architectural lighting applications.
Power Level: 200 W
Current Range: 0.7-4.9A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DMX512
The DALI-certified EUD-240SxxxBT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation, DALI-certified EUD-240SxxxBTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 240 W
Current Range: 0.7 - 6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The DALI-certified, EUD-240SxxxBV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: DALI
The 2nd Generation, DALI-certified EUD-240SxxxBVA series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range.  They are ideal for high bay, tunnel and street lighting applications.
Power Level: 240 W
Current Range: 0.7 - 6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
This series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications. Product maturity for this series allowed us to improve on our design.
Power Level: 240 W
Current Range: 0.7-6.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation EUD-240SxxxDTA series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-240SxxxDTL series is suitable for North American use. They are really in a league of their own. These Controls-Ready, programmable IP67 LED drivers are designed without electrolytic capacitors to ensure an ultra-long lifetime. They provide the full 240W at a wide range of output currents and operate at 90-305Vac. They also include all the enhanced features to provide an industry-leading performance. They are ideal for high bay, high mast, arena and roadway lighting.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
This series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation EUD-240SxxxDVA is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-240SxxxDVL series is suitable for global use (except North America). They are really in a league of their own. These Controls-Ready, programmable IP67 LED drivers are designed without electrolytic capacitors to ensure an ultra-long lifetime. They provide the full 240W at a wide range of output currents and operate at 90-305Vac. They also include all the enhanced features to provide an industry-leading performance. They are ideal for high bay, high mast, arena and roadway lighting.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The DALI-certified EUD-320SxxxBT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 320W at a wide output current range. They are ideal for high bay, high mast, aquaculture and horticulture lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 320 W
Current Range: 1.05-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The DALI-certified EUD-320SxxxBV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 320W at a wide output current range.  They are ideal for high bay, high mast, aquaculture and horticulture lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 320 W
Current Range: 1.05-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The EUD-320SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 320W at a wide output current range. They are ideal for high bay, high mast, aquaculture and horticulture lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 320 W
Current Range: 1.05-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-320SxxxDV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 320W at a wide output current range. They are ideal for high bay, high mast, aquaculture and horticulture lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 320 W
Current Range: 1.05-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-480SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 480W at a wide output current range from 1.4-10A. They are ideal for high bay, high mast, aquaculture and horticulture lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 480 W
Current Range: 1.05-10.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The EUD-480SxxxDV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 480W at a wide output current range from 1.05-10.0A. They are ideal for high bay, high mast, aquaculture and horticulture lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 480 W
Current Range: 1.05-10.0 A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, PWM, Multiple Timers
The high-powered EUD-600SxxxBT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are DALI-certified and designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 600W at a wide output current range.  They are designed to address high power solutions by replacing multiple lower wattage drivers and are ideal for high mast, airport, aquaculture, horticulture, port and sports lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 600 W
Current Range: 1.10-9.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The high-powered EUD-600SxxxBV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are DALI-certified and designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 600W at a wide output current range. They are designed to address high power solutions by replacing multiple lower wattage drivers and are ideal for high mast, airport, aquaculture, horticulture, port and sports lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 600 W
Current Range: 1.10-9.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: DALI, Multiple Timers
The high-powered EUD-600SxxxDT series is suitable for North American use. They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 600W at a wide output current range. They are designed to address high power solutions by replacing multiple lower wattage drivers and are ideal for high mast, airport, aquaculture, horticulture, port and sports lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 600 W
Current Range: 1.10 - 12.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers
The high-powered EUD-600SxxxDV series is suitable for global use (except North America). They consist of Controls-Ready, programmable IP67 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 600W at a wide output current range. They are designed to address high power solutions by replacing multiple lower wattage drivers and are ideal for high mast, airport, aquaculture, horticulture, port and sports lighting applications. These models include the upgraded features of the 2nd Generation EUD series.
Power Level: 600 W
Current Range: 1.1-12.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: Isolated 0 - 10V, PWM, Multiple Timers
The EUG-075SxxxDT series is suitable for North American use. They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 75W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-075SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 75W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-096SxxxDT series is suitable for North American use. They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 96W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-096SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 96W at a wide output current range. They are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-150SxxxDT series is suitable for North American use. They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 150W at a wide output current range. They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.45-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-150SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 150W at a wide output current range. They are ideal for high bay, tunnel and roadway lighting applications.
Power Level: 150 W
Current Range: 0.45-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-192DxxxDT series is suitable for North American use. They consist of programmable IP67 LED drivers that provide two independent output and dimming channels. They operate from 90-305Vac and supply the full 96W per channel at a wide output current range. They are ideal for high bay, tunnel and horticulture applications.
Power Level: 192 W
Current Range: 0.70-4.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: Isolated 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-192DxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers that provide two independent output and dimming channels. They operate from 90-305Vac and supply the full 96W per channel at a wide output current range. They are ideal for high bay, tunnel and horticulture applications.
Power Level: 192 W
Current Range: 0.70-4.0A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: Isolated 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-200SxxxDT series is suitable for North American use. They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 200W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-200SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 200W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-240SxxxDT series is suitable for North American use. They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUG-240SxxxDV series is suitable for global use (except North America). They consist of programmable IP67 LED drivers that provide a flexible, simplified option over the Controls-Ready EUD family. They operate from 90-305Vac and deliver the full 240W at a wide output current range. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7- 6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 5V, 0 - 10V, PWM, Traditional Timer
The EUK-075SxxxDT(TT) series is suitable for North American use. They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305Vac and deliver the full 75W at a wide range of output currents. They are ideal for low bay, tunnel and street lighting applications.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V,10V PWM (DT), Multiple Timers (TT)
The EUK-075SxxxDV(TV) series is suitable for global use (except North America). They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305Vac and deliver the full 75W at a wide range of output currents. They are ideal for low bay, tunnel and street lighting applications.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM (DV), Multiple Timers (TV)
The EUK-096SxxxDT(TT) series is suitable for North American use. They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305 Vac and deliver the full 96W at a wide range of output currents. They are ideal for high bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.7- 3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM
The EUK-096SxxxDV(TV) series is suitable for global use (except North America). They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305 Vac and deliver the full 96W at a wide range of output currents. They are ideal for high bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.7-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM
The EUK-150SxxxDT(TT) series is suitable for North American use. They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305Vac and deliver the full 150W at a wide range of output currents. They are ideal for high bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM (DT), Multiple Timers (TT)
The EUK-150SxxxDV(TV) series is suitable for global use (except North America). They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305Vac and deliver the full 150W at a wide range of output currents. They are ideal for high bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM (DV), Multiple Timers (TV)
The EUK-200SxxxDT(TT) series is suitable for North American use. They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305Vac and deliver the full 200W at a wide range of output currents. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM
The EUK-200SxxxDV(TV) series is suitable for global use (except North America). They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305Vac and deliver the full 200W at a wide range of output currents. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM
The EUK-240SxxxDT(TT) series is suitable for North American use. They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305Vac and deliver the full 240W at a wide range of output currents. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7 - 6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM
The EUK-240SxxxDV(TV) series is suitable for global use (except North America). They consist of simplified, programmable IP67 LED drivers for applications that do not require enhanced features. They operate from 90-305Vac and deliver the full 240W at a wide range of output currents. They are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: 0 - 10V, 10V PWM
The EUP-075SxxxST series is suitable for North American use. They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for low bay, tunnel and street lighting applications.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-075SxxxSV series is suitable for global use (except North America). They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for low bay, tunnel and street lighting applications.
Power Level: 75 W
Current Range: 0.45-2.8A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-096SxxxST series is suitable for North American use. They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-096SxxxSV series is suitable for global use (except North America). They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for low bay, tunnel and street lighting applications.
Power Level: 96 W
Current Range: 0.45-3.5A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-150SxxxST series is suitable for North American use. They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for low bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.45-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-150SxxxSV series is suitable for global use (except North America). They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for low bay, tunnel and street lighting applications.
Power Level: 150 W
Current Range: 0.45-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-200SxxxST series is suitable for North American use. They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-200SxxxSV series is suitable for global use (except North America). They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-240SxxxST series is suitable for North American use. They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7- 6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUP-240SxxxSV series is suitable for global use (except North America). They consist of switch-selectable IP67 LED drivers for applications that require the higher IP rating but not the added dimming controls. They operate from 90-305Vac and are ideal for high bay, high mast, arena and roadway lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: 6 kV DM, 10 kV CM
IP Rating: IP67
Dimming: N/A
The EUR-096SxxxDT(ST) series is suitable for North American use. They consist of Adjustable, IP65 LED drivers with a unique circular shape making them easy to install and integrate to the top of lighting fixtures. They operate from 90-305Vac and provide the full 96W at a wide output current range. They are suitable for indoor and outdoor use and ideal for industrial and bay lighting applications.
Power Level: 96 W
Current Range: 1.4-3.5A
Surge: 4 kV DM, 4 kV CM
IP Rating: IP65
Dimming: 0 - 10V, PWM
The EUR-096SxxxDV(SV) series is suitable for global use (except North America). They consist of Adjustable, IP65 LED drivers with a unique circular shape making them easy to install and integrate to the top of lighting fixtures. They operate from 90-305Vac and provide the full 96W at a wide output current range. They are suitable for indoor and outdoor use and ideal for industrial and bay lighting applications.
Power Level: 96 W
Current Range: 1.4-3.5A
Surge: 4 kV DM, 4 kV CM
IP Rating: IP65
Dimming: 0 - 10V, PWM
The EUR-150SxxxDT(ST) series is suitable for North American use. They consist of Adjustable, IP65 LED drivers with a unique circular shape making them easy to install and integrate to the top of lighting fixtures. They operate from 90-305Vac and provide the full 150W at a wide output current range. They are suitable for indoor and outdoor use and ideal for industrial and bay lighting applications.
Power Level: 150 W
Current Range: 2.45-5.6A
Surge: 4 kV DM, 4 kV CM
IP Rating: IP65
Dimming: 0 - 10V, PWM
The EUR-150SxxxDV(SV) series is suitable for global use (except North America). They consist of Adjustable, IP65 LED drivers with a unique circular shape making them easy to install and integrate to the top of lighting fixtures. They operate from 90-305Vac and provide the full 150W at a wide output current range. They are suitable for indoor and outdoor use and ideal for industrial and bay lighting applications.
Power Level: 150 W
Current Range: 2.45-5.6A
Surge: 4 kV DM, 4 kV CM
IP Rating: IP65
Dimming: 0 - 10V, PWM
The EUR-200SxxxDV(SV) series is suitable for North American use. They consist of Adjustable, IP65 LED drivers with a unique circular shape making them easy to install and integrate to the top of lighting fixtures. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are suitable for indoor and outdoor use and ideal for industrial and bay lighting applications.
Power Level: 200 W
Current Range: 2.45-5.6A
Surge: 4 kV DM, 4 kV CM
IP Rating: IP65
Dimming: 0 - 10V, PWM
The EUR-200SxxxDV(SV) series is suitable for global use (except North America). They consist of Adjustable, IP65 LED drivers with a unique circular shape making them easy to install and integrate to the top of lighting fixtures. They operate from 90-305Vac and provide the full 200W at a wide output current range. They are suitable for indoor and outdoor use and ideal for industrial and bay lighting applications.
Power Level: 200 W
Current Range: 2.45-5.6A
Surge: 4 kV DM, 4 kV CM
IP Rating: IP65
Dimming: 0 - 10V, PWM
The EUR-240SxxxDT(ST) series is suitable for North American use. They consist of Adjustable, IP65 LED drivers with a unique circular shape making them easy to install and integrate to the top of lighting fixtures. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are suitable for indoor and outdoor use and ideal for industrial and bay lighting applications.
Power Level: 240 W
Current Range: 2.8-6.7A
Surge: 4 kV DM, 4 kV CM
IP Rating: IP65
Dimming: 0 - 10V, PWM
The EUR-240SxxxDV(SV) series is suitable for global use (except North America). They consist of Adjustable, IP65 LED drivers with a unique circular shape making them easy to install and integrate to the top of lighting fixtures. They operate from 90-305Vac and provide the full 240W at a wide output current range. They are suitable for indoor and outdoor use and ideal for industrial and bay lighting applications.
Power Level: 240 W
Current Range: 2.8 - 6.7A
Surge: 4 kV DM, 4 kV CM
IP Rating: IP65
Dimming: 0 - 10V, PWM
The HUK-096SxxxDT series is suitable for North American use. They consist of 96W, programmable IP67 LED drivers that operate from 90-305Vac. Their patented metal case allows them to be easily installed in a vertical direction specifically for bay lighting applications.
Power Level: 096 W
Current Range: 0.7-3.5A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0-10V, 10V PWM
The HUK-096SxxxDV series is suitable for global use (except North America). They consist of 96W, programmable IP67 LED drivers that operate from 90-305Vac. Their patented metal case allows them to be easily installed in a vertical direction specifically for bay lighting applications.
Power Level: 0960 W
Current Range: 0.7-3.5A
Surge: DM 4 kV, CM 6 kV
IP Rating: IP67
Dimming: 0-10V, 10V PWM
The HUK-150SxxxDT series is suitable for North American use. They consist of 150W, programmable IP67 LED drivers that operate from 90-305Vac. Their patented metal case allows them to be easily installed in a vertical direction specifically for bay lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP67
Dimming: 0-10V, 10V PWM
The HUK-150SxxxDV series is suitable for global use (except North America). They consist of 150W, programmable IP67 LED drivers that operate from 90-305Vac. Their patented metal case allows them to be easily installed in a vertical direction specifically for bay lighting applications.
Power Level: 150 W
Current Range: 0.7-5.6A
Surge: DM 4 kV, CM 6 kV
IP Rating: IP67
Dimming: 0-10V, 10V PWM
The HUK-200SxxxDT series is suitable for North American use. They consist of 200W, programmable IP67 LED drivers that operate from 90-305Vac. Their patented metal case allows them to be easily installed in a vertical direction specifically for bay lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: DM 4 kV, CM 6 kV
IP Rating: IP67
Dimming: 0-10V, 10V PWM
The HUK-200SxxxDV series is suitable for global use (except North America). They consist of 200W, programmable IP67 LED drivers that operate from 90-305Vac. Their patented metal case allows them to be easily installed in a vertical direction specifically for bay lighting applications.
Power Level: 200 W
Current Range: 0.7-5.6A
Surge: DM 4 kV, CM 6 kV
IP Rating: IP67
Dimming: 0-10V, 10V PWM
The HUK-240SxxxDT series is suitable for North American use. They consist of 240W, programmable IP67 LED drivers that operate from 90-305Vac. Their patented metal case allows them to be easily installed in a vertical direction specifically for bay lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: DM 4 kV, CM 6 kV
IP Rating: IP67
Dimming: 0-10V, 10V PWM
The HUK-240SxxxDV series is suitable for global use (except North America). They consist of 240W, programmable IP67 LED drivers that operate from 90-305Vac. Their patented metal case allows them to be easily installed in a vertical direction specifically for bay lighting applications.
Power Level: 240 W
Current Range: 0.7-6.7A
Surge: DM 4 kV, CM 6 kV
IP Rating: IP67
Dimming: 0-10V, 10V PWM
The DALI-certified LBD-075SxxxBSF series is suitable for global use (except North America). They consist of Controls-Ready, Programmable IP20 LED drivers that offer enhanced features for a top-of-line performance. They operate from 176-305Vac and deliver the full 75W at a wide range of output currents. They are ideal for panel and linear lighting applications.
Power Level: 75 W
Current Range: 0.7 - 2.1A
Surge: 1 kV DM
IP Rating: 20
Dimming: DALI, Push Dimming
The DALI-certified LUD-040SxxxBSF series is suitable for North American use. They consist of Controls-Ready, programmable IP20 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 40W at a wide output current range. They are ideal for dimmable panel and linear lighting applications.
Power Level: 40 W
Current Range: .35-1.5A
Surge: 1 kV DM
IP Rating: IP20
Dimming: DALI, Push Dimming
The LUD-040SxxxDSF series is suitable for North American use. They consist of Controls-Ready, programmable IP20 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 40W at a wide output current range.  They are ideal for dimmable panel and linear lighting applications.
Power Level: 40 W
Current Range: .35-1.5A
Surge: 1 kV DM
IP Rating: IP20
Dimming: 0 - 10V, PWM, Traditional Timer
The 2nd Generation LUD-060SxxxBS2 series is suitable for North American use. They consist of Controls-Ready, programmable IP20 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 60W at a wide output current range.  They are ideal for dimmable panel and linear lighting applications.
Power Level: 60 W
Current Range: .385-2.1A
Surge: 1 kV DM
IP Rating: IP20
Dimming: DALI, Push Dimming
This series is not recommended for new design. Instead, please see the updated features of the the LUD-060SxxxBS2.The DALI-certified LUD-060SxxxBSF series is suitable for North American use. They consist of Controls-Ready, programmable IP20 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 60W at a wide output current range.  They are ideal for dimmable panel and linear lighting applications.
Power Level: 60 W
Current Range: .385-2.1A
Surge: 1 kV DM
IP Rating: IP20
Dimming: DALI
The 2nd Generation LUD-060SxxxDS2 series is suitable for North American use. They consist of Controls-Ready, programmable IP20 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 60W at a wide output current range.  They are ideal for dimmable panel and linear lighting applications.
Power Level: 60 W
Current Range: .385-2.1A
Surge: 1 kV DM
IP Rating: IP20
Dimming: 0 - 10V, PWM, Multiple Timers
This series is not recommended for new design. Instead, please see the updated features of the LUD-060SxxxDS2. The LUD-060SxxxDSF series is suitable for North American use. They consist of Controls-Ready, programmable IP20 LED drivers that are designed to provide enhanced features for top-of-the-line performance. They operate from 90-305Vac and provide the full 60W at a wide output current range.  They are ideal for dimmable panel and linear lighting applications.
Power Level: 60 W
Current Range: .385-2.1A
Surge: 1 kV DM
IP Rating: IP20
Dimming: 0 - 10V, PWM
The LUG-025S105DTE series is suitable for global use. It consists of programmable, IP20 LED drivers that are designed to fill the industry need for a programmable, square, indoor driver with isolated dimming. They operate from 90-305Vac/127-300Vdc and are ideal for fixtures requiring a low profile such as: panel, troffer and downlight applications.
Power Level: 25 W
Current Range: 0.5-1.05A
Surge: 1 kV DM, 2 kV CM
IP Rating: IP20
Dimming: Isolated 0 - 10V
The LUG-040SxxxDTE series is suitable for global use. It consists of 40W programmable, IP20 LED drivers that are designed to fill the industry need for a programmable, square, indoor LED drivers with isolated dimming. They operate from 90-305Vac/127-350Vdc and are ideal for fixtures requiring a low profile such as: panel, troffer and downlight applications.
Power Level: 40 W
Current Range: 0.80-1.50A
Surge: 1 kV DM, 2 kV CM
IP Rating: IP20
Dimming: Isolated 0 - 10V
