This Series has Been Discontinued
- Support Customized Output Current
- High Efficiency
- Open-Lamp Protection, Short-Circuit and Over-Load Protection
- SELV Output
- 5 Year Warranty
Life Time
71,100 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
5.30 x 1.64 x 1.18
Millimeters (L x W x H)
134.5 x 41.5 x 30
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 350 mA | 90 ~ 264 Vac | 36 – 72 Vdc | 25 W | LWC-024S035SSE |
| 500 mA | 25 – 50 Vdc | LWC-024S050SSE | ||
| 700 mA | 18 – 36 Vdc | LWC-024S070SSE | ||
| 1050 mA | 12 – 24 Vdc | LWC-024S105SSE |
