- Input Surge Protection:
- 4kV DM, 6kV CM
- SELV Output
- Suitable for Independent Use
- 5 Year Warranty
Life Time
117,000 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
10.4 x 4.25 x 1.8
Millimeters (L x W x H)
264 x 108 x 45.5
Certifications
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 24 V |
176 ~ 305 Vac |
0 ~ 20.83 A |
500 W |
EBV-500S024SV |
| 28 V | 0 ~ 17.85 A | EBV-500S028SV | ||
| 36 V | 0 ~ 13.88 A | EBV-500S036SV | ||
| 42 V | 0 ~ 11.9 A | EBV-500S042SV | ||
| 48 V | 0 ~ 10.41 A | EBV-500S048SV |
|
