• Low THD, 10% Max up to 240 Vac
  • Compact Metal Case with Excellent Thermal Performance
  • Input Surge Protection: DM 4kV, CM 6kV
  • High Reliability & Long Lifetime: 84,000 Hrs. at 70C Case Temperature
  • IUVP
  • IP67
  • SELV Output
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

84,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
3.15 x 2.55 x 1.26

Millimeters (L x W x H)
80 x 64 x 32

Certifications

Independent Gear Logo

Output
Current		 Input
Voltage
Range		 Output
Voltage
Range		 Max.
Output
Power		 Typical
Efficiency		 Typical
Power Factor		 Model Number
120Vac 220Vac
350 mA 90 ~ 305 Vac/
127 ~ 300 Vdc		 37 ~ 74 Vdc 26 W 88.5% 0.99 0.96 EUC-026S050SVM0003
500 mA 90 ~ 305 Vac/
127 ~ 300 Vdc		 26 ~ 52 Vdc 26 W 88.0% 0.99 0.96 EUC-026S070SVM0004
600 mA 90 ~ 305 Vac/
127 ~ 300 Vdc		 22 ~ 43 Vdc 26 W 88.0% 0.99 0.96 EUC-026S070SVM0002
700 mA 90 ~ 305 Vac/
127 ~ 300 Vdc		 20 ~ 37 Vdc 26 W 87.0% 0.99 0.96 EUC-026S070SVM

Notes:

(1) Certified input voltage range: 120-240Vac.
(2) Measured at 100% load and 220 Vac input.
(3) SELV output, certified to BIS.
(4) For BIS models please click here see the: BIS Models List
