• High Efficiency (Up to 90%)
  • Second Generation with Improved Performance
  • Active Power Factor Correction (Typical 0.95)
  • Constant Current Output
  • IP66 and UL Dry/Damp Location
  • Dimming Control
  • All-Around Protection: OVP, SCP, OLP, OTP
  • SELV & Class 2
  • UL Type TL (Temperature Limited)
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

116,000 hours @ Case Temperature 60°C

Dimensions

Inches (L x W x H)
3.74 x 2.76 x 1.26

Millimeters (L x W x H)
95 x 70 x 32

Certifications

Output Current (mA) Output Voltage Range (Vdc) Max. Output Power (W) Typical Efficiency Typical Power Factor Model Number
0.96 0.95
350 60-120 42 90.0% 0.96 0.95 EUC-042S035DS(PS)
450 47-94 42 89.0% 0.96 0.95 EUC-042S045DS(PS)
530 40-79 42 89.0% 0.96 0.95 EUC-042S053DS(PS)
700 28-56 39 89.0% 0.96 0.95 EUC-042S070DS(PS)
1050 20-38 40 88.0% 0.96 0.95 EUC-042S105DS(PS)
1280 17-32 42 87.0% 0.96 0.95 EUC-042S128DS(PS)
1400 15-30 42 87.0% 0.96 0.95 EUC-042S140DS(PS)
1750 12-24 42 87.0% 0.96 0.95 EUC-042S175DS(PS)
File Name
LED Driver Installation Instructions (Updated March 2015)
Download
LED Driver Installation Guidelines (Updated September 2018)
Download
