This Series is Not Recommended for New Design and has last buy date of 8/31/2023.
We Recommend our EUM-050SxxxDG as a Replacement.
- Dimming Controls:
- DV: 0-10V
- SV: Non-Dimming
- Input Surge Protection:
- 4kV DM, 6kV CM
- SELV Output
- Improved Performance
- 5 Year Warranty
Life Time
93,300 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.77 x 1.77 x 1.38
Millimeters (L x W x H)
172 x 45 x 35
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 350 mA | 90 ~ 305 Vac | 75 – 149 Vdc | 52 W | EUC-052S035DV |
| 450 mA | 58 – 116 Vdc | EUC-052S045DV | ||
| 700 mA | 38 – 75 Vdc | EUC-052S070DV | ||
| 1050 mA | 25 – 50 Vdc | EUC-052S105DV | ||
| 1400 mA | 19 – 37 Vdc | EUC-052S140DV | ||
| 2100 mA | 13 – 25 Vdc | EUC-052S210DV |
File Name |
|---|
LED Driver Installation Instructions (Updated March 2015) |
LED Driver Installation Guidelines (Updated September 2018) |
