- Four Channel Outputs
- Dimming Controls:
- DT: 0-10V
- ST: Non-Dimming
- Input Surge Protection:
- 4kV DM, 6kV CM
- Low Total Harmonic Distortion
- 5 Year Warranty
Life Time
94,800 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
7.40 x 3.46 x 1.50
Millimeters (L x W x H)
188 x 88 x 38
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 350 mA |
90 ~ 305 Vac |
57 – 114 Vdc |
160 W |
EUC-160Q035DT(ST) |
| 450 mA | 45 – 90 Vdc | EUC-160Q045DT(ST) | ||
| 600 mA | 40 – 70 Vdc | EUC-160Q060DT(ST) | ||
| 700 mA | 29 – 57 Vdc | EUC-160Q070DT(ST) | ||
| 1050 mA | 19 – 38 Vdc | EUC-160Q105DT(ST) | ||
| 1400 mA | 14 – 29 Vdc | EUC-160Q140DT(ST) |
|
