- Switch-Selectable Output Current
- Does not require a Programming Tool
- Input Surge Protection:
- 6kV DM, 10kV CM
- SELV Output
- Suitable for Independent Use
- 5 Year Warranty
Life Time
114,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.74 x 2.37 x 1.44
Millimeters (L x W x H)
171 x 60 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 450 – 700 mA | 550 mA |
90 ~ 305 Vac |
117 – 333 Vdc |
150 W |
EUP-150S070SV |
| 700 – 1050 mA | 700 mA | 75 – 214 Vdc | EUP-150S105SV | ||
| 1050 – 1500 mA | 1050 mA | 50 – 143 Vdc | EUP-150S150SV | ||
| 1400 – 2100 mA | 1400 mA | 38 – 107 Vdc | EUP-150S210SV | ||
| 2450 – 3500 mA | 3150 mA | 22 – 61 Vdc | EUP-150S350SV | ||
| 4200 – 5600 mA | 4200 mA | 14 – 36 Vdc | EUP-150S560SV |
|
