- Ultra High Efficiency (Up to 93.5%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Dip-switch
- Non-dimming Control
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP67
- SELV Output
- 5 Years Warranty
Life Time
84,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.35 x 2.66 x 1.56
Millimeters (L x W x H)
212 x 67.5 x 39.7
Certifications
| Adjustable Output Current Range |
Full-Power Current Range |
Default Output Current |
Input Voltage Range |
Output Voltage Range |
Max. Output Power |
Typical Efficiency |
Typical Power Factor |
Model Number | |
| 120Vac | 220Vac | ||||||||
| 500-1050mA | 700-1050mA | 700 mA | 90~305 Vac/ 127~250 Vdc |
114~343Vdc | 240W | 93.5% | 0.99 | 0.96 | EUP-240S105SV |
| 850-1500mA | 1050-1500mA | 1050 mA | 90~305 Vac/ 127~250 Vdc |
80~229Vdc | 240W | 93.5% | 0.99 | 0.96 | EUP-240S150SV |
| 1000-2100mA | 1400-2100mA | 1400 mA | 90~305 Vac/ 127~250 Vdc |
57~171Vdc | 240W | 93.5% | 0.99 | 0.96 | EUP-240S210SV |
| 2000-4200mA | 2800-4200mA | 4200 mA | 90~305 Vac/ 127~250 Vdc |
29 ~ 86Vdc | 240W | 92.5% | 0.99 | 0.96 | EUP-240S420SV |
| 3400-6700mA | 4600-6700mA | 6700 mA | 90~305 Vac/ 127~250 Vdc |
18 ~ 52Vdc | 240W | 92.0% | 0.99 | 0.96 | EUP-240S670SV |
|
