High Efficiency (Up to 93%)
-
Constant Voltage Output
-
Input Surge Protection: DM 4kV, CM 6kV
-
All-Around Protection: OVP, OCP, SCP, OTP
-
IP67
-
SELV Output
- 5 Year Warranty
Life Time
77,200 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
7.83 x 2.66 x 1.56
Millimeters (L x W x H)
199 x 67.5 x 39.5
Certifications
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Typical Efficiency | Typical Power Factor | Model Number |
|---|---|---|---|---|---|---|
| 12 Vdc | 90 ~ 305 Vac | 0~12.5 A | 150 W | 92% | 0.99 @110Vac 0.96 @220Vac |
EUV-150S012SV |
| 24 Vdc | 90 ~ 305 Vac | 0~6.25 A | 150 W | 93% | 0.99 @110Vac 0.96 @220Vac |
EUV-150S024SV |
| 36 Vdc | 90 ~ 305 Vac | 0~4.17 A | 150 W | 93% | 0.99 @110Vac 0.96 @220Vac |
EUV-150S036SV |
| 42 Vdc | 90 ~ 305 Vac | 0~3.57 A | 150 W | 93% | 0.99 @110Vac 0.96 @220Vac |
EUV-150S042SV |
| 48 Vdc | 90 ~ 305 Vac | 0~3.13 A | 150 W | 93% | 0.99 @110Vac 0.96 @220Vac |
EUV-150S048SV |
| 54 Vdc | 90 ~ 305 Vac | 0~2.78 A | 150 W | 93% | 0.99 @110Vac 0.96 @220Vac |
EUV-150S054SV |
|
