- Dimming Controls:
- DSP: 0-10V (compatible with Passive Dimmers)
- SSP: Non-Dimming
- Plastic Housing
- Class 2 and SELV Output
- 5 Year Warranty
Life Time
100,000 hours @ Case Temperature 60°C
Dimensions
Inches (L x W x H)
4.72 x 1.65 x 1.20
Millimeters (L x W x H)
120 x 42 x 30.5
Certifications
| Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|
| 350 mA | 90 ~ 305 Vac | 36 – 72 Vdc | 25 W | LUC-024S035DSP(SSP) |
| 500 mA | 24 – 48 Vdc | 24 W | LUC-024S050DSP(SSP) | |
| 700 mA | 18 – 36 Vdc | LUC-024S070DSP(SSP) | ||
| 1050 mA | 12 – 24 Vdc | LUC-024S105DSP(SSP) |
