• High Efficiency up to 93.0%
  • Constant Output Voltage
  • No Load Power Consumption < 0.5 W
  • Excellent Thermal Performance up to 50C Ambient Temperature
  • Input Surge Protection: DM 4 kV
  • All-Around Protection: OCP, OVP, OTP, SCP
  • Class II
  • SELV Output
  • 5 Years Warranty
Download Data Sheet
Order Here

Life Time

120,000 Hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
6.34 × 2.30 × 1.48

Millimeters (L x W x H)
161 × 58.5 × 37.5

Certifications

Double insulation certification logo

Output Voltage（V） Output Current Range（A） Max. Output Power Typical Efficiency Model Number

12V

0-8.34

100 W

92.0%

LUV-100S012SF

24V

0-4.17

100 W

91.5%

LUV-100S024SF

36V

0-2.78

100 W

92.0%

LUV-100S036SF

48V

0-2.09

100 W

93.0%

LUV-100S048SF
