• Non-Isolated Design with Low Residual Output Voltage
  • Independent Four Output Channels
  • Dynamic Power Transfer (Optional)
  • Ultra High Efficiency (Up to 97%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with Programmability
  • Adjustable Output Current (AOC) with NFC
  • INV Digital Dimming, UART Based Communication Protocol
  • Integrated Power Metering with High Accuracy up to ±1%
  • Dim-to-Off
  • Hold Time Adjustable
  • Fade Time Adjustable
  • Always-on Auxiliary Power: 12Vdc, 500mA
  • Low Inrush Current
  • Output Lumen Compensation
  • End-of-Life Indicator
  • Input Surge Protection: DM 4kV, CM 6kV
  • All-Around Protection: IUVP, IOVP, OVP, SCP, OTP, OPP
  • 5 Years Warranty

Life Time

100,000 hours @ 70°C

Dimensions

7.10 × 5.94 × 2.44 inches
180.4 × 151 × 62 mm



Certifications

Channel Adjustable Output Current Range (A) Full-Power Current Range (A) Default Output Current (A) Output Voltage Range (Vdc) Max. Output Power (W) Typical Efficiency Typical Power Factor 347Vac Typical Power Factor 400Vac Model Number
1 0.21-3.5 2.1-3.5 2.1 180-429 900 97.0% 0.99 0.98 NCU-1K4Q350MP
2 0.14-2.1 1.4-2.1 1.4 57-143 200
3 0.14-2.1 1.4-2.1 1.4 57-143 200
4 0.07-1.4 0.7-1.4 0.7 40-143 100
