• Non-Isolated Class I Driver
  • No Afterglow
  • Dim-to-Off with Standby Power ≤ 0.5W @ 230Vac
  • Dimming Range: 0.1%-100%
  • Max Remote Distance Up to 300 Meters (Dimming and Output)
  • Ultra High Efficiency (Up to 97%)
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with NFC
  • DALI-2 and D4i Certified & DMX-RDM & 3-Timer-Modes Dimmable
  • DALI-2/DMX-RDM Controls up to 44 fps
  • Hold Time Adjustable
  • Fade Time Adjustable
  • Integrated Power Metering with High Accuracy up to ±1%
  • Thermal Sensing and Protection for LED Module
  • Low Inrush Current
  • Output Lumen Compensation
  • End-of-Life Indicator
  • Input Surge Protection: DM 10kV, CM 10kV
  • All-Around Protection: IOVP, IUVP, OVP, SCP, OTP, OPP
  • IP66
  • IK08 Enclosure
  • 5 Years Warranty

Life Time

100,000 Hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
12.20 × 5.71 × 2.76

Millimeters (L x W x H)
310 × 145 × 70

Certifications

Independent Gear Logo

Adjustable
Output
Current
Range (mA)
Full-Power
Current
Range
(mA)
Default
Output
Current
(mA)
Output
Voltage
Range
(Vdc)
Max.
Output
Power
(W)
Typical
Efficiency
Typical Power Factor Model Number
220Vac 480Vac
1.2-2100 1200-2100 1200 176-500 600 97.0% 0.99 0.95 NFS-600S210BC
