- Non-isolated design with low residual output voltage < 3kV
- Independent four output channels
- Dynamic power transfer and traditional power transfer selectable
- Ultra high efficiency (up to 96%)
- Full power at wide output current range (constant power)
- Adjustable output current (AOC) with programmability
- INV digital dimming, UART-based communication protocol
- Integrated power metering with high accuracy up to ±1%
- Dim-to-off
- Hold time adjustable
- Fade time adjustable
- Always-on auxiliary power: 12Vdc, 500mA
- Low inrush current
- Output lumen compensation
- End-of-life indicator
- Input surge protection: DM 6kV, CM 10kV
- All-around protection: IUVP, IOVP, OVP, SCP, OTP, OPP
- 5 Years Warranty
Life Time
96,000 Hours @ Case Temperature 40°C
Dimensions
Inches (L x W x H)
18.66 × 3.54 × 1.91
Millimeters (L x W x H)
474 × 90 × 48.5
Certifications
| Channel | Adjustable Output Current Range (A) | Full-Power Current Range (A)(1) | Default Output Current (A) | Output Voltage Range (Vdc) | Max. Output Power (W) | Typical Efficiency (2) | Typical Power Factor 277Vac |
Typical Power Factor 480Vac |
Model Number (3) |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 0.13–2 | 1.3–2.2 | 1.4 | 200–500 | 660 | 95.5% | 0.99 | 0.95 | NSM-1K2Q200MG |
| 2 | 0.14–2 | 1.4–2.2 | 1.4 | 40–129 | 180 | ||||
| 3 | 0.14–2 | 1.4–2.2 | 1.4 | 40–129 | 180 | ||||
| 4 | 0.14–2 | 1.4–2.2 | 1.4 | 40–129 | 180 |
