•  Non-Isolated Design with Low residual output voltage < 2kV
  •  No Afterglow
  •  Ultra High Efficiency (Up to 96.5%)
  •  Full Power at Wide Output Current Range (Constant Power)
  •  Adjustable Output Current (AOC) with Programmability
  •  Isolated 0-10V/10V PWM/Resistor/3-Timer-Modes Dimmable
  •  Dim-to-Off
  •  Maximum Dimming Level with 9V or 10V Selectable
  •  Fade-time Adjustable
  •  Always-on Auxiliary Power: 12Vdc, 250mA
  •  Low Inrush Current
  •  Output Lumen Compensation
  •  End-of-Life Indicator
  •  Input Surge Protection: DM 4kV, CM 6kV
  •  All-Around Protection: OVP, SCP, OTP
  •  Suitable for Luminaires with Protection Class I
  • 5 Years Warranty
Download Data Sheet
Order Here

Life Time

120,000 hours @ 70C

Dimensions

17.80 in × 1.59 in × 1.57 in
452mm × 40.5mm × 40mm



Certifications

UL Class P, FCC, ENEC, UKCA, CE, CB

Full-Power
Current
Range		 Default
Output
Current		 Input
Voltage
Range		 Output
Voltage
Range		 Max.
Output
Power		 Typical
Efficiency
 Typical
Power Factor
 Model Number
730-1400mA 1100mA 312-528Vac
440-500Vdc		 150-550Vdc 400W 96.5% 0.96 NTL-400S140MP
