•  Controls-Ready
    • Always-On Auxiliary Power: 12Vdc, 250mA
    • Dim-to-Off with Standby Power ≤ 0.5W
  • Isolated Dimming Controls:
    • 0-10V, PWM, Multiple Timers
    • Minimum Dimming Level with 5% or 10% Selectable
    • Maximum Dimming Level with 9V or 10V Selectable
    • Fade Time Adjustable
  • Ultra High Efficiency
  • Low Inrush Current
  • High Level of Built-in Protection:
    • 6kV DM, 6kV CM
  • Input Over Voltage (IOVP) and Input Under Voltage (IUVP) Protection
  • Inventronics Proprietary Digital Dimming Health Monitoring
    • UART Based Communication Protocol
  • Low inrush current
  • End-of-Life Indicator
  • Output Lumen Compensation
  • All-Around Protection: IOVP, IUVP, OVP, SCP, OTP
  • IP66 and IP67 and UL Dry, Damp, Wet Location
  • TYPE HL, for use in a Class I, Division 2 Hazardous
  • 5 Year Warranty

Life Time

120,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
10.71 × 1.71 × 1.24

Millimeters (L x W x H)
272 × 43.5 × 31.5

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
4100mA – 5300mA4100 mA90-305Vac
127 – 300Vdc
30 – 54Vdc220WSUM-220S530MF
