The EUW Dx series is the first dual channel, white color tuning LED driver with IP66 (DF Models) and IP66/IP67 (DV Models) ratings designed for harsh environment applications on the market.  It offers independent control of intensity and color temperature so the user can adjust these separately and continuously.  They provide design flexibility with programmability via software, isolated dimming and operate from 90-305Vac. They are also rugged and reliable with built-in surge protection of 4kV DM, 6kV CM and a long lifetime over 100,000 hrs. They also supply a quality, flicker-free performance with output lumen compensation. There are several different model options to accommodate a multitude of applications and regions. The EUW DV are CCC and CE certified and the EUW DF are UL recognized.



Data Sheet

EUW-040DxxxDF

The EUW-040DxxxDF is suitable for North American use. They consist of IP66, White Tuning LED drivers, They offer design flexibility by adjusting color temperature and intensity separately. They are programmable, equipped with isolated dimming and provide built-in surge protection. They operate from 90-305Vac and provide the full 40W of power per channel at a wide output current range.  They are ideal for tunnel, signage, street and landscape lighting applications.
Power Level: 40 W
Current Range: 0.7-1.05A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP66
Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers
Data Sheet

EUW-040DxxxDV

The EUW-040DxxxDV is suitable for global use (except North America). They consist of IP66/IP67, White Tuning LED drivers, They offer design flexibility by adjusting color temperature and intensity separately. They are programmable, equipped with isolated dimming and provide built-in surge protection. They operate from 90-305Vac and provide the full 40W of power per channel at a wide output current range.  They are ideal for tunnel, signage, street and landscape lighting applications.
Power Level: 60 W
Current Range: 0.7-1.05A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers
Data Sheet

EUW-060DxxxDF

The EUW-060DxxxDF is suitable for North American use. They consist of IP66, White Tuning LED drivers, They offer design flexibility by adjusting color temperature and intensity separately. They are programmable, equipped with isolated dimming and provide built-in surge protection. They operate from 90-305Vac and provide the full 60W of power per channel at a wide output current range.  They are ideal for tunnel, signage, street and landscape lighting applications.
Power Level: 60 W
Current Range: 0.7-1.05A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP66
Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers
Data Sheet

EUW-060DxxxDV

The EUW-060DxxxDV is suitable for global use (except North America). They consist of IP66/IP67, White Tuning LED drivers, They offer design flexibility by adjusting color temperature and intensity separately. They are programmable, equipped with isolated dimming and provide built-in surge protection. They operate from 90-305Vac and provide the full 60W of power per channel at a wide output current range.  They are ideal for tunnel, signage, street and landscape lighting applications.
Power Level: 60 W
Current Range: 0.7-1.05A
Surge: 4 kV DM, 6 kV CM
IP Rating: IP66/IP67
Dimming: Isolated 1 - 5V, 1 - 10V, PWM, Multiple Timers
