- Ultra High Efficiency
- Full Power at a Wide Range of Output Currents
- Low Inrush Current (lpeak ≤20 A @ 277 Vac)
- Isolated 0-10V/PWM/3-Timer-Modes Dimmable
- Controls-Ready:
- Always-On Auxiliary Power 12Vdc/250mA
- Dim-to-Off with Low Standby Power
- UART Based Two-Way Communication
- via Inventronics Proprietary Digital Dimming
- High Level Surge Protection:
- 6kV DM, 10kV CM
- Output Lumen Compensation
- End-of-Life Indicator
- Input Over Voltage (UOVP) and Input Under Voltage (IUVP) Protection
- IP66/IP67
- 5 Year Warranty
Life Time
100,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
11.22 x 5.55 x 1.91
Millimeters (L x W x H)
285 x 141 x 48.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 2600 – 3500 mA | 3500 mA | 176 ~ 305 Vac 190 ~ 250 Vdc |
171 – 462 Vdc | 1200 W | EBM-1K2S350MG |
| 3950 – 5250 mA | 5250 mA | 114 – 304 Vdc | EBM-1K2S525MG | ||
| 5550 – 7400 mA | 7400 mA | 81 – 217 Vdc | EBM-1K2740MG |
|
File Name
|
|---|
|
LED Driver Installation Instructions
|
|
LED Driver Installation Guidelines (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
