- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with NFC
- Isolated 1-10V/3-Timer-Modes Dimmable
- Output Lumen Compensation
- End-of-Life Indicator
- Long Lifetime Over 100K Hours at 75°C Case Temperature
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP20 Design and Suitable for Outdoor Applications in Luminaires with IP>54
- SELV Output
- Suitable for Luminaires with Protection Class I and II
- Complies with Zhaga Interface Specification Book 13
- 8 Year Warranty
Life Time
109,000 hours @ Case Temperature 75°C
Dimensions
Inches (L x W x H)
5.24 x 3.03 x 1.30
Millimeters (L x W x H)
133 x 77 x 33
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 300 – 450 mA | 450 mA | 176 ~ 305 Vac 171 ~ 275 Vdc |
28 – 84 Vdc | 25 W | EBS-025S045DT2 |
| 45 – 700 mA | 700 mA | 18 – 56 Vdc | EBS-025S070DT2 | ||
| 700 – 1050 mA | 1050 mA | 12 – 36 Vdc | EBS-025S105DT2 |
|
File Name
|
|---|
|
LED Driver Installation Guidelines (Updated September 2018)
|
|
Inventronics DALI Driver Programmer Manual Instruction (Updated November 2016)
|
|
Programming Interface for DALI-Program (Updated May 2015)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
