Not Recommended for New Design
We Recommend the EBS-120SxxxDT2 as a Replacement

  • Programmable Dimming Controls:
    • 0-10V, PWM, Multiple Timer
  • Controls-Ready:
    • Always-On Auxiliary Power 12Vdc/200mA
  • Dim-to-Off with Low Standby Power
  • High Level Surge Protection:
    • 6kV DM, 10kV CM
  • Thermal Sensing and Protectino for LED module
  • Output Lumen Compensation
  • Suitable for Luminaires with Protection Class I and II
  • 7 Year Warranty
Download Data Sheet
Order Here

Life Time

120,000 hours @ Case Temperature 75°C

Dimensions

Inches (L x W x H)
6.50 x 2.76 x 1.56

Millimeters (L x W x H)
165 x 70 x 39.5

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
500 – 700 mA 530 mA

176 ~ 305 Vac
190 ~ 250 Vdc

 86 – 240 Vdc

120 W

 EBS-120S070DTE
700 – 1050 mA 700 mA 57 – 171 Vdc EBS-120S105DTE
1050 – 1500 mA 1050 mA 40 – 114 Vdc EBS-120S150DTE
File Name
LED Driver Installation Guidelines (Updated September 2018)
Download
Programming Interface Device Driver Install First (Updated March 2015)
Download
Design-In Guide for Programmable Drivers (Updated September 2018)
Download
