Not Recommended for New Design
We Recommend the EBS-165SxxxBT2 as a Replacement
- Programmable
- Full Power at a Wide Range of Output Currents
- Dimming Controls:
- DALI, AC DIm, Multiple Timers
- Controls-Ready:
- Always-On Auxiliary Power 12Vdc/200mA
- Dim-to-Off with Low Standby Power
- High Level Surge Protection:
- 6kV DM, 10kV CM
- Thermal Sensing and Protection for LED module
- Output Lumen Compensation
- Suitable for Luminaires with Protection Class I and II
- Built-in Use for Outdoor Applications
- Independent Use for Indoor Applications with Optional Endcap
- 7 Year Warranty
Life Time
102,000 hours @ Case Temperature 75°C
Dimensions
Inches (L x W x H)
6.70 x 3.94 x 1.58
Millimeters (L x W x H)
170 x 100 x 40
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 450 – 700 mA | 530 mA | 176 ~ 305 Vac 190 ~ 250 Vdc |
115 – 356 Vdc | 160 W | EBS-160S070BTE |
| 700 – 1050 mA | 700 mA | 76 – 229 Vdc | EBS-160S105BTE |
|
File Name
|
|---|
|
LED Driver Installation Guidelines (Updated September 2018)
|
|
Inventronics DALI Driver Programmer Manual Instruction (Updated November 2016)
|
|
Programming Interface for DALI-Program (Updated May 2015)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
