- Ultra High Efficiency (Up to 96%)
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with NFC
- DALI-2 and D4i Certified
- DALI-2 & DMX-RDM Dimmable
- Multi-channel (up to 3*DT6 or 3*DMX) Operating Mode
- DALI-2/DMX-RDM Controls Up to 44 fps
- Dim-to-Off
- Dimming Range: 0.1%–100%
- Always-on Auxiliary Power: 24Vdc, 125mA (Except DMX-RDM mode)
- Low Inrush Current
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IUVP, IOVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
52,000 hours @ Case Temperature 80°C
Dimensions
Inches (L x W x H)
11.22 × 5.55 × 1.91
Millimeters (L x W x H)
285 × 141 × 48.5
Certifications
| Channel | Adjustable Output Current Range (mA) | Full-Power Current Range (mA) | Default Output Current (mA) | Output Voltage Range (Vdc) | Max. Output Power (W) | Typical Efficiency | Typical Power Factor | Model Number | |
|---|---|---|---|---|---|---|---|---|---|
| 220Vac | 480Vac | ||||||||
| 1 | 14-1400 | 950-1400 | 1050 | 150-286 | 267 | 96.0% | 0.99 | 0.96 | EFM-800T140BG |
| 2 | 14-1400 | 950-1400 | 1050 | 150-286 | 267 | 96.0% | 0.99 | 0.96 | |
| 3 | 14-1400 | 950-1400 | 1050 | 150-286 | 267 | 96.0% | 0.99 | 0.96 | |
|
