• Adjustable Output Current (AOC) with Programmability
  • High Input Voltage Next Generation Platform
  • Multiple Isolated Dimming Functionalities:
    • 1-10V, 10V PWM, Multiple Timers
  • Input Surge Protection:
    • 6 kV DM, 10 kV CM
  • Output Lumen Compensation
  • End-of-Life Indicator
  • SELV Output
  • IP66/IP67 and UL Dry/Damp/Wet Location
  • UL Class P
  • TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Year Warranty
Download Data Sheet
Order Here

Life Time

105,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
6.34 x 2.66 x 1.52

Millimeters (L x W x H)
161 x 67.5 x 38.5

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
700 – 1050 mA 700 mA

249 ~ 528 Vac

 72 – 214 Vdc

150 W

 ESM-150S105DT
1050 – 1500 mA 1050 mA 50 – 143 Vdc ESM-150S150DT
1400 – 2100 mA 1400 mA 36 – 107 Vdc ESM-150S210DT
2800 – 4200 mA 3150 mA 18 – 54 Vdc ESM-150S420DT
File Name
LED Driver Installation Instructions (Updated September 2018)
Download
Programming Interface Device Driver Install First (Updated 3-3-2015)
Download
Design-In Guide for Programmable Drivers (Updated September 2018)
Download
Inventronics Constant Power Programmer Manual Instruction (Updated December 2020)
Download
