- High Input Voltage: 249 – 528 Vac
- Panel Mount Connectors Offering One-Step Connection
- Provides Easy Installation for New Facilities or Retrofit
- Brackets Offer Multiple Installation Options to Fit any Configuration
- Programmable with Full-Power at a Wide Output Current Range
- Isolated Dimming Controls:
- 0-10V, PWM, Multiple Timers
- Minimum Dimming Level with 5% or 10% Selectable
- Maximum Dimming Level with 9V or 10V Selectable
- Fade Time Adjustable
- Controls-Ready
- Always-On Auxiliary Power: 12Vdc, 250mA, 3W (Transient Peak Power up to 10W)
- Dim-to-Off
- Low Inrush Current
- Inventronics Proprietary Digital Dimming Health Monitoring
- UART Based Communication Protocol
- High Level of Built-in Protection:
- 6kV DM, 10kV CM
- Input Under Voltage (IUVP) and Input Over Voltage (IOVP) Protection
- Extruded Metal Enclosure Available in Silver or White
- White Provides Higher Reflectivity for Grow Applications
- End-of-Life Indicator
- Output Lumen Compensation
- SELV Output Models Available
- IP66 and IP67 and UL Dry, Damp, Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous
- 5 Year Warranty
Life Time
101,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
12.01 × 6.56 × 1.95
Millimeters (L x W x H)
305 × 166.5 × 49.5
Certifications
Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
---|---|---|---|---|---|
2.6 – 3.5A | 3.5 A | 249-528 Vac 352 – 500 Vdc | 171 – 462 Vdc | 1,200W | ESM-1K2S350MGS |
3.95 – 5.25A | 5.25 A | 114 – 304 Vdc | ESM-1K2S525MGS | ||
5.55 – 7.4A | 7.4 A | 81 – 217Vdc | ESM-1K2S740MGS |
File Name |
---|
LED Driver Installation Instructions (Updated September 2018) |
Programming Interface Device Driver Install First (Updated March 2015) |
Design-in Guide for Programming Drivers (Updated September 2018) |
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018) |
