• High Input Voltage: 249 – 528 Vac
  • Panel Mount Connectors Offering One-Step Connection
    • Provides Easy Installation for New Facilities or Retrofit
  • Brackets Offer Multiple Installation Options to Fit any Configuration
  • Programmable with Full-Power at a Wide Output Current Range
  • Isolated Dimming Controls:
    • 0-10V, PWM, Multiple Timers
    • Minimum Dimming Level with 5% or 10% Selectable
    • Maximum Dimming Level with 9V or 10V Selectable
    • Fade Time Adjustable
  • Controls-Ready
    • Always-On Auxiliary Power: 12Vdc, 250mA, 3W (Transient Peak Power up to 10W)
    • Dim-to-Off
  • Low Inrush Current
  • Inventronics Proprietary Digital Dimming Health Monitoring
    • UART Based Communication Protocol
  • High Level of Built-in Protection:
    • 6kV DM, 10kV CM
  • Input Under Voltage (IUVP) and Input Over Voltage (IOVP) Protection
  • Extruded Metal Enclosure Available in Silver or White
    • White Provides Higher Reflectivity for Grow Applications
  • End-of-Life Indicator
  • Output Lumen Compensation
  • SELV Output Models Available
  • IP66 and IP67 and UL Dry, Damp, Wet Location
  • TYPE HL, for use in a Class I, Division 2 Hazardous
  • 5 Year Warranty

Life Time

102,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
10.83 x 5.95 x 1.81

Millimeters (L x W x H)
275 x 151 x 46

Certifications

Full-Power Current RangeDefault Output CurrentInput Voltage RangeOutput Voltage RangeMax. Output PowerModel Number
1.25 – 1.7 A1.7 A249 – 528 Vac
352 – 500 Vdc
200 – 544 Vdc680 WESM-680S170MGS
1.8 – 2.4 A2.1 A141.5 – 378 VdcESM-680S240MGS
2.6 – 3.5 A3.5 A97.1 – 262 VdcESM-680S350MGS
4.2 – 5.6 A5.6 A60.7 – 163 VdcESM-680S560MGS
6.3 – 8.4 A8.4 A40.4 – 108 VdcESM-680S840MGS
12.6 – 15.0 A15.0 A22.6 – 54 VdcESM-680S15AMGS
