- Programmable, Enabling Hundreds of Configurations
- Controls-Ready:
- Always-On Auxiliary Power: 12V, 200mA
- Dim-to-Off with Low Standby Power
- Dimming Controls:
- DALI, Multiple TImers
- High Level of Built-in Surge Protection:
- 6kV DM, 10kV CM
- Output Lumen Compensation
- Thermal Sensing and Protection for LED Module
- Class 2 and SELV Output
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
- 7 Year Warranty
Life Time
97,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.86 x 3.86 x 1.77
Millimeters (L x W x H)
225 x 98 x 44.8
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 1050 – 1500 mA | 1400 mA |
90 ~ 305 Vac |
107 – 305 Vdc |
320 W |
EUD-320S150BV |
| 1540 – 2200 mA | 2100 mA | 73 – 208 Vdc | EUD-320S220BV | ||
| 2240 – 3200 mA | 2800 mA | 50 – 143 Vdc | EUD-320S320BV | ||
| 3220 – 4600 mA | 4200 mA | 35 – 100 Vdc | EUD-320S460BV | ||
| 4690 – 6700 mA | 6700 mA | 24 – 68 Vdc | EUD-320S670BV |
|
File Name
|
|---|
|
Inventronics DALI Driver Programmer Manual Instruction (Updated November 2016)
|
|
Programming Interface for DALI-Program (Updated May 2015)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
