This Series is Not Recommended for New Design
We Recommend our EUM-075SxxxDG as a Replacement
- Programmable, Enabling Hundreds of Configurations
- Dimming Controls:
- 0-5V, 0-10V, PWM, Traditional Timer
- Input Surge Protection:
- 6kV DM, 10kV CM
- SELV Output
- 7 Year Warranty
Life Time
99,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
5.91 x 2.66 x 1.44
Millimeters (L x W x H)
150 x 67.5 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 450 – 700 mA | 530 mA |
90 ~ 305 Vac |
54 – 167 Vdc |
75 W |
EUG-075S070DV |
| 700 – 1050 mA | 700 mA | 36 – 107 Vdc | EUG-075S105DV | ||
| 1190 – 1750 mA | 1400 mA | 22 – 63 Vdc | EUG-075S175DV | ||
| 1920 – 2800 mA | 2100 mA | 14 – 39 Vdc | EUG-075S280DV |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-In Guide for Programmable Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
