This Product has been Discontinued.
- Ultra High Efficiency (Up to 93.5%)
- Full Power at Wide Output Current Range (Constant Power)
- 0-10V/10V PWM Dimmable (DV models)
- 3 Timer Modes Dimmable (TV models)
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OVP, SCP, OTP
- IP67
- SELV Output
- 5 Year Warranty
Life Time
85,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
7.95 x 2.66 x 1.56
Millimeters (L x W x H)
202 x 67.5 x 39.7
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 700 – 1050 mA | 700 mA |
90 ~ 305 Vac |
95 – 286 Vdc |
200 W |
EUK-200S105DV(TV) |
| 1050 – 1500 mA | 1050 mA | 67 – 190 Vdc | EUK-200S150DV(TV) | ||
| 1400 – 2100 mA | 1400 mA | 48 – 143 Vdc | EUK-200S210DV(TV) | ||
| 2450 – 3500 mA | 2800 mA | 29 – 82 Vdc | EUK-200S350DV(TV) | ||
| 3850 – 5600 mA | 4900 mA | 18 – 52 Vdc | EUK-200S560DV(TV) |
|
