EUM 30W LED Drivers with Flying Leads
  • Programmable, Without the need of Powering on the Driver
  • Isolated Dimming Controls:
    • 1-5V, 1-10V, 10V PWM, Multiple Timers
  • Built-in Surge Protection:
    • 4kV DM, 6kV CM
  • Output Lumen Compensation
  • Class 2 Models Available
  • SELV Output Models Available
  • UL Class P
  • Type HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • IP66 Rated with UL Dry, Damp
  • 5 Year Warranty

Life Time

120,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
3.75 x 2.52 x 1.44

Millimeters (L x W x H)
95 x 64 x 36.5

Certifications

Full-Power Current RangeDefault Output CurrentInput Voltage RangeOutput Voltage RangeMax. Output PowerModel Number
300 – 500 mA350 mA90 ~ 305 Vac
127 – 300 Vdc
30 – 100 Vdc30 WEUM-030S050DF
550 – 1050 mA700 mA17 – 54 VdcEUM-030S105DF

File Name
LED Driver Installation Instructions
Programming Interface Device Driver Install First (Updated March 2015)
Design-in Guide for Programming Drivers (Updated September 2018)
