- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable
- Output Lumen Compensation
- Input Surge Protection: DM 4kV, CM 6kV
- All-Around Protection: OVP, SCP, OTP
- IP66/IP67
- SELV Output
- Suitable for Luminaires with Protection Class I and II
- 5 Year Warranty
Life Time
103,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
3.75 x 2.52 x 1.44
Millimeters (L x W x H)
95 x 64 x 36.5
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 550 – 900 mA | 700 mA | 90 ~ 305 Vac 127 – 300 Vdc |
28 – 91 Vdc | 50 W | EUM-050S090DE |
| 920 – 1500 mA | 1050 mA | 17 – 54 Vdc | EUM-050S150DE |
|
File Name
|
|---|
|
LED Driver Installation Instructions
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-in Guide for Programming Drivers (Updated September 2018)
|
