• DALI-2 D4i Certified
    • Offers Intra-Luminaire Solutions and Health Monitoring
    • Integrated 16Vdc Bus Power Supply based on DALI-2
  • Integrated AC Power Monitoring with High Accuracy up to ±1%
  • Wireless Programming via Near Field Communication (NFC)
    • Compatible with Zhaga Book 24 Programmers
  • Dimming Controls:
    • Multiple Timers
  • Controls-Ready
    • Always-On Auxiliary Power: 24Vdc, 125mA, 3W (Transient Peak Power up to 10W)
    • Dim-to-Off
  • Optimized, More Compact Form Factor
  • High Level of Built-in Surge Protection:
    • 6kV DM, 10kV CM
  • End-of-Life Indicator
  • Thermal Sensing and Protection for LED Module
  • Simplified Design for Easier Hi-Pot Testing
  • Output Lumen Compensation
  • SELV Output Models Available
  • IP66 and IP67 and UL Dry, Damp, Wet Location
  • UL Class P
  • TYPE HL, for use in a Class I, Division 2 Hazardous
  • 7 Year Warranty

Life Time

101,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
7.91 x 2.66 x 1.52

Millimeters (L x W x H)
201 x 67.5 x 38.5

Certifications

Full-Power Current RangeDefault Output CurrentInput Voltage RangeOutput Voltage RangeMax. Output PowerModel Number
700 – 1050 mA700 mA90 ~ 305 Vac
127 – 300 Vdc
115 – 343 Vdc240 WEUM-240S105BT
1050 – 1500 mA1050 mA80 – 229 VdcEUM-240S150BT
2150 – 3500 mA2150 mA35 – 111 VdcEUM-240S350BT
4200 – 6700 mA4900 mA18 – 57 VdcEUM-240S670BT

File Name
LED Driver Installation Instructions (Updated March 2015)
Programming Interface Device Driver Install First (Updated March 2015)
Design-in Guide for Programming Drivers (Updated September 2018)
Programming Interface Installation Instructions (Updated April 2015)
Programming Interface Operating Instructions (Updated January 2016)
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
