• Programmable, Without the need of Powering on the Driver
    • Full Power at a Wide Output Current Range
  • New Global Cable Design to Reduce SKUs (with UL)
  • Isolated Dimming Controls:
    • 1-5V, 1-10V, PWM, Multiple Timers
  • Optimized, More Compact Form Factor
  • High Level of Built-in Surge Protection:
    • 6kV DM, 10kV CM
  • Output Lumen Compensation
  • SELV Output Models Available
  • IP66 and IP67 and UL Dry, Damp, Wet Location
  • TYPE HL, for use in a Class I, Division 2 Hazardous
  • EUM-240SxxxDG Models: Global Cable to Reduce Inventory SKUs
  • EUM-240SxxxDB Models: BIS Certified
  • 5 Year Warranty

Life Time

111,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
8.82 x 3.15 x 1.75

Millimeters (L x W x H)
224 x 80 x 44.5

Certifications

Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
700 – 1050 mA 700 mA 90 ~ 305 Vac
127 – 300 Vdc
153 – 457 Vdc 320 W EUM-320S105DG
1050 – 1500 mA 1050 mA 107 – 305 Vdc EUM-320S150DG
1750 – 2500 mA 2100 mA 64 – 183 Vdc EUM-320S250DG
2850 – 5000 mA 4900 mA 32 – 112 Vdc EUM-320S500DG
5350 – 7600 mA 6700 mA 21 – 60 Vdc EUM-320S760DG

File Name
LED Driver Installation Instructions (Updated March 2015)
Programming Interface Device Driver Install First (Updated March 2015)
Design-in Guide for Programming Drivers (Updated September 2018)
Programming Interface Installation Instructions (Updated April 2015)
Programming Interface Operating Instructions (Updated January 2016)
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
