Features
- Compact Metal Case with Excellent Thermal Performance
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with T4T (Tuner4TRONIC)
- Isolated 1(0)-5V / 1(0)-10V / PWM / Resistor / AstroDIM (Timer) Dimmable
- Dim-to-Off with Standby Power ≤ 0.5 W
- Adjustable Dimming Curve
- Always-on Auxiliary Power: 12Vdc, 100mA on Specific Models
- End-of-Life Indicator
- Override Dimming
- Constant Lumen
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: OTP, OVP, SCP
- 5-year warranty
Applications
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
- Suitable for Luminaires with Protection Class I
- Suitable for Luminaires with Protection Class I and II on Specific Models
Life Time
120,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.73 x 2.36 x 1.31
Millimeters (L x W x H)
171 x 60 x 33.4
Certifications
| Adjustable Output Current Range (mA) | Full Power Current Range (mA) | Default Output Current (mA) | Nominal Output Voltage Range (Vdc) | Maximum Output Power (W) | Typical Efficiency | Power Factor λ | Product Name | |
|---|---|---|---|---|---|---|---|---|
| – | 120Vac | 230Vac | – | |||||
| 53-700 | 530-700 | 530 | 142-378 | 200 | 94.0% | 0.99 | 0.96 |
IT 0-10 200/100-277/0A7 P67 y |
| 70-1050 | 700-1050 | 700 | 95-286 | 200 | 94.0% | 0.99 | 0.96 | IT 0-10 200/100-277/1A05 P67 y |
| 350-5600 | 3500-5600 | 4200 | 18-57 | 200 | 94.0% | 0.99 | 0.96 | IT 0-10 200/100-277/5A6 P67 y |
|
