Features
- Compact metal housing with excellent thermal performance
- Delivers full power across a wide output current range (constant power design)
- Adjustable Output Current (AOC) via T4T (Tuner4TRONIC)
- Multi-mode dimming: Isolated 1(0)-5V, 1(0)-10V, PWM, resistor, and AstroDIM (timer)
- Dim-to-Off functionality with ≤ 0.5 W standby power
- Adjustable dimming curve for optimized lighting control
- Always-on 12Vdc auxiliary power (100mA on specific models)
- End-of-life indicator for proactive maintenance
- Dimming override capability
- Constant lumen output over lifetime
- Input surge protection: DM 6kV, CM 10kV
- Comprehensive protection: Over-temperature (OTP), over-voltage (OVP), and short-circuit (SCP)
- 5-year warranty
Applications
- IP66/IP67 rated and UL Dry/Damp/Wet location compliant
- TYPE HL: certified for Class I, Division 2 hazardous locations
- Compatible with Class I luminaires
- Compatible with Class I and II luminaires (on specific models)
Life Time
120,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
7.91 x 2.36 x 1.31
Millimeters (L x W x H)
201 x 60 x 33.4
Certifications
Adjustable Output Current Range (mA) | Full Power Current Range (mA) | Default Output Current (mA) | Nominal Output Voltage Range (Vdc) | Maximum Output Power (W) | Typical Efficiency | Power Factor λ | Product Name | |
---|---|---|---|---|---|---|---|---|
– | 120Vac | 230Vac | – | |||||
53-700 | 530-700 | 530 | 171-453 | 240 | 94.5% | 0.99 | 0.96 | IT 0-10 240/100-277/0A7 P67 y |
70-1050 | 700-1050 | 700 | 115-343 | 240 | 94.0% | 0.99 | 0.96 | IT 0-10 240/100-277/1A05 P67 y |
420-6700 | 4200-6700 | 4900 | 18-57 | 240 | 94.0% | 0.99 | 0.96 | IT 0-10 240/100-277/6A7 P67 y |
File Name
|
---|
LED Driver Installation Instructions
|
Programming Interface Device Driver Install First (Updated March 2015)
|
Design-in Guide for Programming Drivers (Updated September 2018)
|
