Features
- Compact Metal Case with Excellent Thermal Performance
- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with T4T(Tuner4TRONIC)
- Isolated 1(0)-5V/1(0)-10V/PWM/Resistor/AstroDIM(Timer) Dimmable
- Dim-to-Off with Standby Power ≤ 0.5 W
- Adjustable Dimming Curve
- Always-on Auxiliary Power: 12Vdc, 100mA on Specific Models
- End-of-Life Indicator
- Override Dimming
- Constant Lumen
- Input Surge Protection: DM 4kV, CM 6kV
- All-Around Protection: OTP, OVP, SCP
- Class 2 & SELV output.
- 5 Years Warranty
Application
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
- Suitable for Luminaires with Protection Class I
- Suitable for Luminaires with Protection Class I and II on Specific Models
Life Time
104,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
3.74 x 2.52 x 1.26
Millimeters (L x W x H)
95 x 64 x 32
Certifications
| Adjustable Output Current Range(mA) | Full Power Current Range(mA) | Default Output Current (mA) | Nominal Output Voltage Range(Vdc) | Maximum Output Power(W) | Typical Efficiency | Power Factor λ | Product Name | |
|---|---|---|---|---|---|---|---|---|
| 120Vac | 230Vac | |||||||
| 55-900 | 550-900 | 700 | 28~91 | 50 | 91.0% | 0.99 | 0.96 | ITO-10 50/100-277/0A9 P67 E |
| 92-1500 | 920-1500 | 1050 | 17~54 | 50 | 91.0% | 0.99 | 0.96 | ITO-10 50/100-277/1A5 P67 E |
|
File Name
|
|---|
|
LED Driver Installation Instructions
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-in Guide for Programming Drivers (Updated September 2018)
|
