The LMT-080SxxxSTF model is not recommended for new design. It has limited availability until the last buy date of 01/31/25.
- Ultra High Efficiency (Up to 94%)
- Adjustable Output Current (AOC) with External Resistor
- Full Power at Wide Output Current Range (Constant Power)
- Flicker- Free
- Non-dimming Control
- 89,000 Hours Lifetime at 70°C Case Temperature
- Input Surge Protection: DM 1kV, CM 2kV
- Suitable for Luminaires with Protection Class I
- Complies with Zhaga Interface Specification Book 13
- Non-Isolated Design
- 5 Year Warranty
Life Time
89,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
11.02 x 1.18 x 0.83
Millimeters (L x W x H)
280 x 30 x 21
Certifications
| Adjustable Output Current Range |
Full-Power Current Range |
Default Output Current |
Input Voltage Range | Output Voltage Range | Max. Output Power | Typical Efficiency |
Typical Power Factor |
Model Number |
|---|---|---|---|---|---|---|---|---|
| 250-500mA | 350-500mA | ﹤250mA |
198 – 264 Vac 190 – 250 Vdc |
96 – 229Vdc | 80 W | 94.0% | 0.98 | LMT-080S050STF |
| 340-700mA | 500-700mA | ﹤340mA | 68 – 160Vdc | 94.0% | LMT-080S070STF | |||
| 500-1050mA | 700-1050mA | ﹤500mA | 45 – 114Vdc | 93.0% | LMT-080S105STF |
|
