The LUD-060SxxxDS2 model is not recommended for new design. It has limited availability and will be sold while supplies last.
- Dim-to-off with Standby Power ≤ 0.5 W
- Always-on Auxiliary Power: 12Vdc, 200mA
- Thermal Sensing and Protection for LED Module
- Full Power at 70-100% Max. Current (Constant Power)
- Flicker-Free
- 0-10V/PWM/3 Timer-Modes Dimmable
- Output Lumen Compensation
- 69,000 Hour Lifetime at 70ºC Case Temperature
- Class II, Class 2 & SELV
- Suitable for Built-in Use
- Class P, UL Listed Versions Available (See Note 4)
- 5 Year Warranty
Life Time
69,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
14.88 x 1.18 x 0.83
Millimeters (L x W x H)
378 x 30 x 21
Certifications
| Output Current Range (mA) | Full-Power Current Range (mA) | Default Output Current (mA) | Output Voltage Range (Vdc) | Max. Output Power (W) | Typical Efficiency | Power Factor | Model Number |
|---|---|---|---|---|---|---|---|
| 19.3-550 | 385-550 | 530 | 31-156 | 60 | 90.5% | 0.99 | LUD-060S055DS2 |
| 27.3-780 | 546-780 | 700 | 22-110 | 60 | 90.5% | 0.99 | LUD-060S078DS2 |
| 38.5-1100 | 770-1100 | 1050 | 16-78 | 60 | 90.5% | 0.99 | LUD-060S110DS2 |
| 52.5-1500 | 1050-1500 | 1400 | 12-57 | 60 | 89.5% | 0.99 | LUD-060S150DS2 |
| 73.5-2100 | 1470-2100 | 2100 | 8-40 | 60 | 88.0% | 0.99 | LUD-060S210DS2 |
|
