Not Recommended for New Design. We Recommend the EBM-1K2SxxxMG or ESM-1K2SxxxMG as a Replacement.
- Selected by IES for the 2018 Progress Report
- Eliminates Need to use Multiple Drivers in High Power Applications
- Programmable, Enabling Hundreds of Configurations
- Controls-Ready:
- Always-On Auxiliary Power: 12V, 200mA
- Dim-to-Off with Standby Power ≤ 2.5W
- Isolated Dimming Controls:
- 0-10V, PWM, Multiple Timers
- High Level of Built-in Surge Protection:
- 6kV DM, 10kV CM
- Output Lumen Compensation
- Thermal Sensing and Protection for LED Module
- 5 Year Warranty
Life Time
100,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
11.02 x 6.89 x 2.99
Millimeters (L x W x H)
280 x 175 x 76
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 3360 – 4200 mA | 4200 mA |
180 ~ 528 Vac |
143 – 357 Vdc |
1200 W |
EFD-1K2S420DV |
| 4480 – 5600 mA | 5600 mA | 108 – 268 Vdc | EFD-1K2S560DV | ||
| 5920 – 7400 mA | 7000 mA | 81 – 202 Vdc | EFD-1K2S740DV |
|
