• Independent Dual Output Channels
  • Independent Dual Dimming Channels
  • 100W Channel Power Transfer (Optional)
  • Hot-plugging Protection
  • Parallel LED Protection
  • Full Power at Wide Output Current Range (Constant Power)
  • Adjustable Output Current (AOC) with Programmability
  • Isolated 0-10V/PWM/Resistor/3-Timer-Modes Dimmable
  • Adjustable Dimming Curve
  • INV Digital Dimming, UART Based Communication Protocol
  • Dim-to-Off
  • Hold Time Adjustable
  • Fade Time Adjustable
  • Always-on Auxiliary Power: 12Vdc, 250mA
  • Low Inrush Current
  • Output Lumen Compensation
  • End-of-Life Indicator
  • Input Surge Protection: DM 6kV, CM 10kV
  • All-Around Protection: IOVP, IUVP, OVP, SCP, OTP
  • IP66/IP67 and UL Dry/Damp/Wet Location
  • TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
  • 5 Year Warranty

Life Time

119,000 hours @ Case Temperature 70°C

Dimensions

Inches (L x W x H)
12.76 × 5.67 × 1.91

Millimeters (L x W x H)
324 × 144 × 48.5





Certifications

Channel Full-Power Current Range Default Output Current Input Voltage Range Output Voltage Range Max. Output Power Model Number
1 460 – 6100 mA 6100 mA 249 – 528 Vac
352 – 500 Vdc
110 – 195 Vdc 900 W ESM-1K0D610MT
2 180 – 2100 mA 1850 mA 34 – 54 Vdc 100W
Power Transfer
1 510 – 6800 mA 6800 mA 249 – 528 Vac
352 – 500 Vdc
110 – 195 Vdc 1000W ESM-1K0D610MT
2 0A 0A 0Vdc 0W
