- Programmable, Enabling Hundreds of Configurations
- Controls-Ready:
- Always-On Auxiliary Power: 12V, 200mA
- Dim-to-Off with Low Standby Power
- Dimming Controls:
- 0-10V, PWM, Multiple Timers
- Digital Dimming
- High Level of Built-in Surge Protection:
- 6kV DM, 10kV CM
- Output Lumen Compensation
- Thermal Sensing and Protection for LED Module
- Class 2 and SELV Output
- TYPE HL, for use in a Class I, Division 2 Hazardous (Classified) Location
- 7 Year Warranty
Life Time
100,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
8.03 x 2.66 x 1.56
Millimeters (L x W x H)
204 x 67.5 x 39.7
Certifications
| Full-Power Current Range | Default Output Current | Input Voltage Range | Output Voltage Range | Max. Output Power | Model Number |
|---|---|---|---|---|---|
| 700 – 1050 mA | 700 mA | 90 ~ 305 Vac 100 – 300 Vdc |
75 – 214 Vdc | 150 W | EUD-150S105DTA |
| 1400 – 2100 mA | 1400 mA | 38 – 107 Vdc | EUD-150S210DTA | ||
| 2450 – 3500 mA | 3150 mA | 22 – 61 Vdc | EUD-150S350DTA | ||
| 3850 – 5600 mA | 4200 mA | 14 – 39 Vdc | EUD-150S560DTA |
|
File Name
|
|---|
|
LED Driver Installation Instructions (Updated March 2015)
|
|
LED Driver Installation Guideline (Updated September 2018)
|
|
Programming Interface Device Driver Install First (Updated March 2015)
|
|
Design-in Guide for Programming Drivers (Updated September 2018)
|
|
Programming Interface Installation Instructions (Updated April 2015)
|
|
Programming Interface Operating Instructions (Updated January 2016)
|
|
Inventronics Constant Power Programmer Manual Instruction (Updated April 2018)
|
