- Full Power at Wide Output Current Range (Constant Power)
- Adjustable Output Current (AOC) with Programmability
- Isolated 0-10V/PWM/3-Timer-Modes Dimmable
- INV Digital Dimming, UART Based Communication Protocol
- Dim-to-Off with Standby Power ≤ 0.5 W
- Always-on Auxiliary Power: 12Vdc, 250mA, 3W (Transient Peak Power up to 10W)
- Output Lumen Compensation
- End-of-Life Indicator
- Input Surge Protection: DM 6kV, CM 10kV
- All-Around Protection: IUVP, IOVP, OVP, SCP, OTP
- IP66/IP67 and UL Dry/Damp/Wet Location
- TYPE HL, for Use in a Class I, Division 2 Hazardous (Classified) Location
- 5 Year Warranty
Life Time
104,000 hours @ Case Temperature 70°C
Dimensions
Inches (L x W x H)
6.34 x 2.66 x 1.44
Millimeters (L x W x H)
161 x 67.5 x 36.5
Certifications
| Adjustable Output Current Range (mA) | Full-Power Current Range (mA)(1) | Default Output Current (mA) | Output Voltage Range (Vdc) | Max. Output Power (W) | Typical Efficiency(2) | Typical Power Factor | Model Number(3)(5)(6) |
|---|---|---|---|---|---|---|---|
| 70-1050 | 700-1050 | 700 | 72-214 | 150 | 93.5% | 0.99 | EUM-150S105MG |
| 105-1500 | 1050-1500 | 1050 | 50-143 | 150 | 93.0% | 0.99 | EUM-150S150MG |
| 140-2100 | 1400-2100 | 1400 | 36-107 | 150 | 92.5% | 0.99 | EUM-150S210MG |
| 280-4200 | 2800-4200 | 3150 | 18-54 | 150 | 91.5% | 0.99 | EUM-150S420MG |
|
